TMB – Solaris Flare Q+ LR

TMB

The World Famous Flare in a New Linear Format!

SKU: N/A Categories: , , ,
Clear

Description

The World Famous Flare in Linear Format!

Flare Q+ Technology™! Amazing new possibilities with maximum output of over 58,000 Lumens – and QUIET!

BRIGHT! Over 1000 Watt brightness (in Turbo Mode)

QUIET! Perfect for stage and studio!

POWERFUL OPTIONS! Three modes for maximized performance + full compatibility with all generations
of Flares. A perfect match for the award-winning Flare in an entirely new package.

Features

  • Theatre Mode: Quiet, effectively silent operation
  • Turbo Mode: Maximum output, yet still very quiet!
  • The same world class dimming, colors, smoothness, control features, and flicker-free performance
  • Calibration mode allows matching of intensity AND COLOR of Flares of all vintages and types

Additional information

Weight 11 kg
Light Sources

Flare LR Q+ 1m: 108 CREE© XML LEDs
Flare Half LR Q+ 0.5m: 54 CREE© XML LEDs
Controllable “Pixels”

Flare LR Q+ 1m: 1, 2, 3, 4, 6, 12
Flare Half LR Q+ 0.5m: 1, 2, 3, 6
Beam Spread

36°
Average Colour Wavelength (manufacturer rated)

4- R, G, B, W
Red: 625 nm
Green: 530 nm
Blue: 460 nm
White: >5700K
Refresh Rate

1200 Hz
Intensity control

16bit or 8bit
Control

DMX512 + RDM
AC Power

100-277 VAC Universal Input, 50/60 Hz
Cooling

Active cooling
Operating Temperature

20 to +40 °C
DMX Channels

Flare LR Q+ 1m: 3-56 depending on control mode
Flare Half LR Q+ 0.5m: 3-32 depending on control mode
DMX Connectors

In/Out – XLR5 F/M
Max. Power Draw

Flare LR Q+ 1m: 1400 W
Flare Half LR Q+ 0.5m: 600 W
Power Connectors

In- PowerCON 20A blue
Fixing

Adjustable yoke
Unit Dimensions (HxWxD)

Flare LR Q+ 1m: 10.3 x 39.3 x 4.7 in [26.3 x 99.8 x 12 cm] with yoke
Flare Half LR Q+ 0.5m: 11.6 x 19.7 x 4.7 in [28 x 50 x 12 cm] with yoke
Shipping Dimensions (HxWxD)

Flare LR Q+ 1m: 12 x 42 x 11 in [30.5 x 106.7 x 27.9 cm]
Flare Half LR Q+ 0.5m: TBD
Unit Weight

Flare LR Q+ 1m: 24.3 lb [11 kg]
Flare Half LR Q+ 0.5m: 18.3 lb [8.3 kg]
Shipping Weight

Flare LR Q+ 1m: 35 lb [15.9 kg]
Flare Half LR Q+ 0.5m: TBD
