Robert Juliat – Bizet Fresnel 370 LF/MF

Robert Juliat

The Bizet 370LF and 370MF set a new benchmark for LED Fresnels, with a powerful 500W variable white LED delivering consistent output at any colour temperature (3000–6300K). The 370LF offers manual focus adjustment, while the 370MF provides motorised focus via DMX. Silent, precise, and robust, they’re perfect for theatre, broadcast, and live performance.

SKU: N/A Categories: , , ,
Clear

Description

The Bizet 370LF and 370MF set a new standard in LED Fresnel fixtures. Equipped with a powerful 500W variable white LED source, it delivers full output at any chosen colour temperature without compromise.

This cutting-edge engine ensures high-quality white light across the spectrum, offering exceptional colour rendering and a beautifully smooth, even beam.

The 370MF model is equipped with motorised focus to adjust beam size remotely.

The 370LF has manual control of focus adjustment with focusing knob from the rear.

Compact and quiet, the Bizet combines precise control and robust construction.

Ideal for theatre, broadcast, and live events, it brings versatility, reliability, and performance to any lighting environment.

Features

  • 500W LED source
  • Colour temperature adjustment whites from 3000 to 6300 K
  • Rotating barndoors with 4 individually rotating blades
  • Adjustable response time by DMX protocol
  • Compatible with DMX & RDM
  • Choice of different PWM dimming frequencies
  • 8 or 16 bit dimming and strobe function
  • Local setup: DMX address and mode, dimming curve and
  • response time through 4-button display with automatic light
  • switch-off
  • Choice of square or linear dimming curves
  • Smooth focus adjustment from the rear of the fixture(370LF model) or motorised focus adjustment via DMX control (370MF model)
  • Tilt reference on hanging yoke for rapid re-positioning
  • Silent operation

Additional information

Optical

Calibrated tunable white source: to ensure consistency between fixtures
Optical adjustment: extended aperture range possible to obtain a tighter beam and a more powerful very wide angle
Long life: outstanding operational lifetime expectation, no need to replace lamps, low maintenance
Powerful tunable white: maximum LED power guaranteed whatever the colour temperature is
Beam shaping : efficient barndoors in any focus position
Electronic dimmer: dimming without clipping or cut-out at low intensity levels; high quality smoothing
No colour shift: colour temperature remains the same when dimming
Optics

Characteristics

Type: Single lens
Range: 12° to 40° (Beam angle) 7,5° to 60° configuration possible
Lens: 200 mm Fresnel lens

Gel filter
Standard size: Shape: Square
Standard size: 215×215 mm (8.5×8.5 in)
Remote control

Data protocol:
USITT DMX512-A
RDM / Art-Net / sACN
Data IN connector: 5 pins XLR male + etherCON RJ45
Data OUT connector: 5 pins XLR female
Construction

Housing: Steel sheet – Aluminium
Colour: Black
Cooling: Low noise variable fan
Maximum ambient temperature (Ta): 40°C (104°F)
Maximum case temperature (Tc): °C (°F)
Total heat dissipation: 2 017 BTU/h
Ingress Protection (IP) rating: IP20
Electrical compatibility

220/230 V – 50 Hz
245 V – 50 Hz
110/120 V – 60 Hz
208 V – 60 Hz
220/230 V – 60 Hz
100 V – 50 Hz
100 V – 60 Hz
Selector: automatic detection
Power input

Type: removable power cord with compatible powerCON® TRUE1 connector (included)
Cable: H07RNF 3G1.5
Length: 3 m (9.8 ft)
Power connector: CEE 7/7 (2P+E NF/Schuko)
Power Supply Unit

PSU: Internal – Electronic PSU – Flicker free with PFC
Control: Local / DMX
Protection: Mains: 2x 10A 1P1D breaker – UL /
Power thru: compatible powerCON® TRUE1 – Maximum of 5 units (230 V) / 2 units (120 V)

Downloads

Data Sheet Bizet 370LF Download
Data Sheet Bizet 370MF Download
