Panasonic-PT-RQ35-Series-3-Chip-DLP-Projector-FrontPanasonic-PT-RQ35-Series-3-Chip-DLP-Projector-Front

Panasonic – PT-RQ35K2 30,000 lm 3-Chip DLP™ Projector

Panasonic

Vivid reds and truer blues heighten realism for ultra-detailed 4K image reproduction.

30,500 lm, 3-Chip DLP™, 4K+

Key features

  • Laser 3-chip DLP, 32.000 lumens (centre), 4K (With Quad Pixel Drive On)
  • Lamp-free laser projection with dust resistant liquid cooling system for 20000 hours maintenance free operation
  • Smart Projector Control with NFC for mobile access to network con­figuration such as IP address setup
  • Preactivated Upgrade Kits for Geo Pro Software
  • Two blue and one red laser module expands colour-gamut reproduction
SKU: PT-RQ35K2 Categories: , , , ,

Description

Revolutionizing Projection with Streamlined Workflow

With high brightness and jaw-dropping image quality, the light and compact PT-RQ35K2 Series 3-Chip DLP™ projector eases the logistical burden with more efficient transport, installation, and storage. Save resources and enjoy greater convenience especially when backyard space is limited.

Spellbinding Picture Quality

A combination of two blue and one red laser expands color-space reproduction over the
PT-RQ32K. Vivid red and pure blue reproduction heightens realism for an immersive experience and takes high-resolution content to the next level.

Original Cooling System Secures Projection Stability

Dedicated airflow path, cooling system, and finless radiator reinforce reliability. Dynamic Digital Control regulates red laser output and cooling for consistent image quality. Expect 20,000 hours*5 of maintenance-free projection with backup input*6 and laser failover circuitry minimizing interruptions.

*1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped.
*2 Measurement, measuring conditions, and method of notation all comply with American National Standards Institute standards. Value is the average of all products when shipped.
*3 Average light-output value of all shipped products measured at the center of screen in NORMAL Mode.
*4 Maximum physical resolution 3840 x 2400 pixels with Quad Pixel Drive [ON].
*5 Around this time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast Contents, NORMAL Mode, Dynamic Contrast [3], temperature 35 °C (95 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of airborne particulate matter. Estimated time until light output decreases to 50 % will vary depending on environment.
*6 Primary and backup terminal assignment is fixed. Input signals must be identical.

Video

3-Chip DLP™ Projectors “PT-RQ35K series”

World’s Smallest and Lightest 30,000 lm 3-Chip DLP™ 4K Projector* Streamlines Workflow Management.
For more detail, please visit the below.

Additional information

Weight 69.8 kg
Projector type

3-Chip DLP™ projector
Display method

DLP™ chip x 3, DLP™ projection system
Display Device -> Panel size

24.4 mm (0.96 in) diagonal (16:10 aspect ratio)
Display Device -> Number of pixels

2,304,000 (1920 x 1200 pixels) x 3
Light source

Laser diodes (Blue LD, Red LD)
Light output *1

30,500 lm
Light output (ANSI)

30,500 lm
Light output (Center) *1 *2

32,000 lm (Center)
Time until light output declines to 50 % -> NORMAL *3

20,000 hours [NORMAL]
Time until light output declines to 50 % -> ECO *3

24,000 hours [ECO]
Time until light output declines to 50 % -> QUIET *5

26,000 hours [QUIET]
Resolution

PT-RQ35K : 4K (3840 x 2400 pixels) (Quad Pixel Drive: ON)PT-RZ34K : WUXGA (1920 x 1200 pixels)
Contrast Ratio (typ.) *1

20,000:1 (Full On/Full Off, Dynamic Contrast [3])
Screen size (diagonal)

1.78–25.4 m (70–1,000 in),1.78–15.24 m (70–600 in) with ET-D75LE8/ET-D3LET80,3.05–15.24 m (120–600 in) with ET-D75LE95,5.08–15.24 m (200–600 in) with ET-D3LEU100/ET-D3LEW200
Center-to-corner zone ratio *1

90%
Lens

Optional (no lens included with this model)
Lens shift -> Vertical(from center of screen)　 *4

±55 % (+78 %, +68 % with ET-D75LE95, ±48 % with ET-D3LEW200, ±44 % with ET-D75LE6/ET-D3LEW60) (powered)
Lens shift -> Horizontal(from center of screen)　 *4

±20 % (±15 % with ET-D75LE6/ET-D3LEW60/ET-D3LEW200, ±12 % with ET-D75LE95, +25 %, 0 % with ET-D3LEU100) (powered)
Keystone correction range

Vertical: ±45 ° (± 40 ° with ET-D75LE10/ET-D3LEW10/ET-D75LE20/ET-D3LES20, ±28 ° with ET-D75LE6/ET-D3LEW60, ±22 ° with ET-D3LEW50, ±15 ° with ET-D3LEW200, ±8 ° with ET-D3LEU100, +5 ° with ET-D75LE95),Horizontal: ±40 ° (±15 ° with ET-D3LEW50/ET-D75LE6/ET-D3LEW60, ±5 ° with ET-D3LEU100/ET-D3LEW200, 0 ° with ET-D75LE95)When [VERTICAL KEYSTONE] and [HORIZONTAL KEYSTONE] are used simultaneously, correction cannot be made exceeding a total of 55 °.
Installation

Ceiling/floor, front/rear, free 360-degree installation
Terminals -> SDI IN

BNC x 1 : 3G/HD-SDI input(PT-RZ34K only)
Terminals -> HDMI™ IN

HDMI x 1 (Deep Color, compatible with HDCP 2.2, 4K/60p signal input)*5
Terminals -> DVI-D IN

DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP) (Single-link only)(PT-RZ34K only)
Terminals -> MULTI PROJECTOR SYNC IN

BNC x 1(PT-RQ35K only)
Terminals -> MULTI PROJECTOR SYNC OUT

BNC x 1(PT-RQ35K only)
Terminals -> MULTI SYNC IN/ 3D SYNC 1 IN/OUT (dual purpose)

BNC x 1(PT-RZ34K only)
Terminals -> MULTI SYNC OUT/ 3D SYNC 2 OUT (dual purpose)

BNC x 1(PT-RZ34K only)
Terminals -> SERIAL IN

D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
Terminals -> SERIAL OUT

D-sub 9-pin (male) x 1 for link control (RS-232C compliant)
Terminals -> REMOTE 1 IN

M3 stereo mini-jack x 1 for wired remote control
Terminals -> REMOTE 1 OUT

M3 stereo mini-jack x 1 for link control
Terminals -> REMOTE 2 IN

D-sub 9-pin (female) x 1 for external control (parallel)
Terminals -> DIGITAL LINK IN / LAN

RJ-45 x 1 for network and DIGITAL LINK connection (HDBaseT™ compliant), 100Base-TX, compatible with Art-Net, PJLink™ (Class 2), Deep Color, HDCP 2.2, 4K/60p signal input*5
Terminals -> LAN

RJ-45 x 1 for network connection, PJLink™ (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible
Terminals -> DC OUT

USB Type A x 2 (for power supply, DC 5 V total of 2 A)
Terminals -> USB TYPE A

USB connector (Type A) x 1 for optional Wireless Module (AJ-WM50 Series)/USB Memory Stick
Terminals -> SLOT

PT-RQ35K : SLOT 1/SLOT 2 (total two terminals, vacant) for interface boards, SLOT NX compatiblePT-RZ34K : SLOT (one terminal, vacant) for interface boards, SLOT NX compatible
Power supply

AC 200 V–240 V (Light output will decrease when using the projector with AC 100 V to AC 120 V)
Maximum power consumption

2,550 W2,450 W
On-mode power consumption(Operating mode) -> Normal

PT-RQ35K : [NORMAL]　2,060 WPT-RZ34K : [NORMAL]　2,010 W
On-mode power consumption(Operating mode) -> Eco

PT-RQ35K : [ECO]　1,650 WPT-RZ34K : [ECO]　1,590 W
On-mode power consumption(Operating mode) -> Quiet *13 *14

PT-RQ35K : [QUIET]　1,370 WPT-RZ34K : [QUIET]　1,310 W
Standby power consumption -> Normal

PT-RQ35K : 14 WPT-RZ34K : 13 W
Cabinet materials

Molded plastic
Filter

No
Operation noise -> Normal *1

49 dB [NORMAL]
Operation noise -> Quiet *1

46 dB [QUIET]
Dimensions (W x H x D)

Approx. 598 x 353 x 780 mm (23 17/32˝ x 13 29/32˝ x 30 23/32˝) (not including protruding parts)
Dimensions (W x H x D) -> Width (not including protruding parts)

598 mm (23 17/32˝)
Dimensions -> Height (not including protruding parts)

353 mm (13 29/32˝)
Dimensions -> Depth (not including protruding parts)

780 mm (30 23/32˝)
Operating environment -> Operating temperature *8 *9

0–45 °C (32–113 °F)
Operating Environment -> Operating humidity (No condensation)

10–80 % (no condensation)
Applicable software

Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software, Smart Projector Control for iOS/Android™
Body Colour

Black
Gross Dimensions (W x H x D in mm)

Approx. 790 x 702 x 957 mm
Gross Weight (Kg)

84.4 kg/186.1 lbs
NFC

Yes
EAN

RQ35K2EJ: 5025232977079
RQ35K2E: 8887549880698
Terminals -> DisplayPort™ IN

ー
Operation noise -> Eco

49 dB [ECO]
Active 3D

No
SDM

No
Footnote Description

1. When [OPERATING MODE] is set to [NORMAL].
2. Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped.
3. Measurement, measuring conditions, and method of notation all comply with American National Standards Institute standards. Value is the average of all products when shipped.
4. Average light-output value of all shipped products measured at the center of the screen.
5. Around this time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast Contents, Normal Mode, Dynamic Contrast [3], temperature 35 °C (95 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of airborne particulate matter. Estimated time until light output declines to 50 % varies depending on environment.
6. Lens shift is not supported on the ET-D3LEW50.
7. 4K signals are converted to WUXGA (1920 x 1200 pixels) only for the PT-RZ34K2 / PT-RZ34K.
8. Average value. May differ depending on the actual unit.
9. When optional AJ-WM50 wireless module is attached, operating temperature range becomes 0–40 °C (32–104 °F). The operating environment temperature should be between 0 °C (32 °F) and 40 °C (104 °F) if the projector is used at an altitude between 1,400 m (4,593 ft) and 4,200 m (13,780 ft).
10. Some applications listed are currently subject to temporary limitations. For details, please click here.

Downloads

PT-RZ34K Data Sheet Download
PT-RQ35K Data Sheet Download
