MDG – theONE

Mdg

 The award-winning theONE’s revolutionary technology means this fully digital atmospheric generator creates fog or haze effects from a single source. Its construction and features make theONE™, perfect for rental and international touring.

SKU: M0011010 Categories: , , ,

Description

The award-winning theONE’s revolutionary technology means this fully digital atmospheric generator creates fog or haze effects from a single source. Its construction and features make theONE™, perfect for rental and international touring.

Features

Dual mode: Haze and Fog

Seamless switching between haze and fog modes. 100% duty cycle.

APS™ (Automatic Purging System)

This system purges the heating module after the first heating cycle and after every emission of haze/fog preventing residual build up and clogging.

Networking capabilities

theONE™ is the first atmospheric generator with networking capabilities. It can be controlled through its DMX/RDM connector or RJ45 node (Pathport embedded, ACN, ART-Net, ETCNet 2 & 3 and SHOWNet protocols). USB 2.0 Link connector for updates.

ARS™ (Automatic Refill System)

Specially designed to give maximum, consecutive, non-stop hours of haze/fog without interruption, theONE™ automatically refills its internal fluid reservoir from our external 20 L (5.3 US gallons) container of MDG Neutral fluid as required.

Integral Touring Fan

External dual-position, adjustable fan with dedicated control channel which travels in its own compartment within the touring cradle. Can be mounted above or below haze/fog output to adjust directional flow.

Total running time

theONE™, running at full intensity, will generate 308 hours of haze and 20 hours of fog from its 20 L (5.3 US gallons) fluid container. Gas bottle will need to be changed at 50 hours for haze and 15 hours for fog. This can be done during operation without interruption of fog or haze emission.

Operating voltage

theONE™ is unique in being the only atmospheric generator to offer automatic detection of universal voltage rating from 100-250 VAC, 50/60 Hz, single phase.

Touring cradle

theONE™ cradle contains the generator, its fan and a convenient tool drawer, and accommodates our 20 L (5.3 US gallons) fluid container and, uniquely, all known sizes of 9 kg (20 lb) CO2 or N2 gas bottle, within a single robust aluminium frame. Exceeding PLASA rigging standards the cradle is designed for rigging, stacking and rolling and sized to fit standard trucks/containers. The touring cradle ensures theONE™ is fit and ready for worldwide touring.

Certification

theONE™ is a truly global product being CSA and UL certified, CE declaration.

Video

MDG – theONE

Revolutionary technology means this fully digital atmospheric generator creates fog or haze effects from a single source.

Additional information

Weight 23 kg
Haze Mode

Fluid consumption: 65 ml (2.20 oz) at 2.07 bar (30 psi) per hour / max output

Haze volume control: Yes – variable

Gas consumption (CO2 or N2): 0.35 kg (0.77 lb)  per hour / max output

APS™ (Automatic Purging System): Yes – standard

Haze Colour: Pure white

Particle size: 0.5 – 0.7 micron

Total running time: 308 hours (50 hours – gas) 20 L (5.3 US gallons) container, full intensity

Fluid type: MDG Neutral
Fog Mode

Fog volume: 100 m3 (3.531 ft3) per minute / max output

Fog volume control: Yes – variable

Gas consumption (CO2 or N2): 1.16 kg (2.56 lb) per hour / max output

APS™ (Automatic Purging System): Yes – standard

Fog colour: Pure white

Particle size: 0.5 – 0.7 micron

Total running time: 20 hours (15 hours – gas) 20 L (5.3 US gallons) container, full intensity

Fluid type: MDG Neutral
Operation

Operating voltage: 100 – 250 VAC, 50/60 Hz
Power consumption: 1100 – 1480 watts
Approval: CE certified, CSA, UL approved
Warm-up time: < 8 minutes
Physical - Generator

Shipping weight: 25 kg (55 lb)
DMX: Yes, input-output
RJ45: Yes – ACN
Display: LCD, backlit, 5-button command
Height: 61 cm (24”)
Width: 25 cm (10”)
Depth: 30 cm (12”)
Physical - Cradle

Weight: 33.5 kg (74 lb)
Shipping weight: 36 kg (80 lb)
Total operating weight: 120 kg (265 lb) with 2 North-American gas bottles and a full 20 L (5.3 US gallons) fluid container
DMX fan: Yes – Touring Version only
Truss mounting: Yes – 3 x 750 kg rated coupling holes
Height: 106 cm (42”)
Width: 76 cm (30”)
Depth: 61 cm (24”)
