MDG – Me1 WPE

Mdg

MDG takes fog to the great outdoors

SKU: M0021557 Categories: , , ,

Description

Me1 WPE, the first and smallest in our powerful Me family of fog generators, now available in a weatherproof version that’s ready, come rain or shine.

Features

Weatherproof Enclosure

With its weatherproof and dust-resistant enclosure this IP55-rated WPE version is ideal for outdoor use.

Second personality

MAX 3000APS configuration setting.

100% duty cycle

At all output levels Me1 produces a high-quality, consistent fog as long as there is fluid and gas.

Single fog output

With its single nozzle, the maximum fog output is 100 m3 (3,531 ft3) per minute.

Fluid consumption

At maximum output (2.76 bar / 40 psi) Me1 uses only 1 L (0.26 US gallon) of fluid per hour.

APS™ (Automatic Purging System)

APS™ (Automatic Purging System)

This system purges the heating module after the first heating cycle and after every emission of fog preventing residual build up and clogging.

Variable fog output

0-100% fog output control from your DMX/RDM device, or direct local control.

Numerous control options

4-button LCD user interface, 3 standard USITT DMX512 channels, XLR-5 connectors, RDM compliant.

Additional information

Weight 24.9 kg
Maximum fog output

100 m3 (3,531 ft3) per minute

Fluid consumption

1 L (30 oz / 0.26 US gallon) per hour at 2.76 bar / 40 psi

Gas type

CO2 or N2

Gas consumption

1 kg (2.2 lb) per hour at 2.76 bar / 40 psi

Control

4-button LCD user interface, 3 standard DMX512 channels, XLR-5 connectors, RDM compliant.

Reservoir capacity

2.5 L (0.66 US gallon)

APS™ (Automatic Purging System)

Standard

Fog colour

Pure white

Particle size

0.5 – 0.7 microns

Warm-up time

8 minutes (maximum)

Fluid type

MDG Neutral

Operating voltage

100 – 250 VAC, 50/60 Hz single phase

Power consumption

715 W

Enclosure

Weatherproof and dust-resistant
IP55-rated

Dimension

Length: 34 cm (13.4”)
Width: 48.8 cm (19.2”)
Height: 60.7 cm (23.9”)
Shipping weight: 34 kg (75 lb) with flight case

Approval

CB, CSA and UL Certified. CE Declaration

Downloads

User Guide Download
