MDG – ATMe WPE

Mdg

The finest haze on the market… loves rainy weather

SKU: M0021556 Categories: , , ,

Description

The ATMe WPE is the weatherproof version of the ATMe haze generator, and the perfect solution for theme parks, outdoor festivals and events, come rain or shine.

Features

Extremely quiet operation

Noise emission (at 1m/3.3ft): 45.4 dB in standard mode. The theatre mode reduces the fan speed depending on haze output level.

Variable haze output

0-100% haze output control from your DMX / RDM device. 100% duty cycle.

Weatherproof enclosure

With its weatherproof and dust-resistant enclosure this IP55-rated WPE version is ideal for outdoor use.

Lowest fluid consumption on the market

At 1.38 bar (20 psi) ATMe uses only 55 ml (1.86 oz) of fluid per hour to give a total running time of 46 hours from its 2.5 L (0.66 US gallon) reservoir.

APS™ (Automatic Purging System)

This system purges the heating module after the first heating cycle and after every emission of haze preventing residual build up and clogging.

Longest hanging time

Our MDG Neutral fluid is specially created for the longest hanging time.

Numerous control options

4-button LCD user interface, 3 standard USITT DMX512 channels, XLR-5 connectors, RDM compliant.

Additional information

Weight 26.8 kg
Fluid consumption

110 ml (3.3 oz) per hour at 2.76 bar (40 psi)

CO2 consumption

0.36 kg (0.8 lb) per hour at 2.76 bar (40 psi)

Reservoir capacity

2.5 L (0.66 US gallon)

APS™ (Automatic Purging System)

Standard

Haze colour

Pure white

Particle size

0.5 – 0.7 micron

Total running time

23 hours at 2.76 bar (40 psi) with a full tank

Warm-up time

8 minutes (maximum)

Fluid type

MDG Neutral

Operating voltage

100 – 250 VAC, 50/60 Hz single phase

Power consumption

715 W

Noise emission

45.4 dB (A) at 1 m (3.3 ft)

Enclosure

Weatherproof and dust-resistant
IP55-rated

Dimensions

Length: 46.7 cm (18.4”)
Width: 48.8 cm (19.2”)
Height: 60.7 cm (23.9”)
Shipping weight: 35.8 kg (79 lb) with flight case

Approval

CB, CSA and UL Certified. CE Declaration

Downloads

User Guide Download
