Magic-FX-FlameblazerMagic-FX-Flameblazer

Magic FX – Flameblazer

Magic FX

Meet the Flameblazer, a state-of-the-art liquid flamethrower. Extremely fast and reliable because of its high-quality internal pump, dual ignition and premium electronics.

SKU: MFX1401 Categories: , , ,

Description

Meet the Flameblazer, a state-of-the-art liquid flamethrower. Extremely fast and reliable because of its high-quality internal pump, dual ignition and premium electronics. The robust grips and waterproof housing are finishing touches to the compact design. Fire 6 (S nozzle), 8 (M nozzle), or 10 (L nozzle) meter flames. A 5 liter fluid can fits in the internal compartment, which is secured by a locking lid.

The Flameblazer is secured with the SFX Safety Arm System to ensure maximum safety. Override it with other safety systems with the Arm Override Switch. Place the Flameblazer on a stage or truss, activate the safety system and fire away!

Features

  • Meet the Flameblazer Compact, standalone plug and play flame head.
  • Dual ignition Fast. Responsive. Reliable.
  • Interchangeable S, M and L nozzles.
  • 10M Maximum output.
  • 5L Fluid can compartment.

Video

MAGICFX FLAMEBLAZER®

Meet the MAGICFX FLAMEBLAZER®, the new state of the art liquid flame system. This next level flame unit is fast and responsive. It’s very reliable because of its dual ignition and its fully integrated, key-activated enable circuit. Safety first!

Additional information

Weight 18.7 kg
Consumption

Consumable type: Isopar G, H or L (L recommended) Isopropanol Alcohol
Consumption: S nozzle: ≈ 1.4 L/min M nozzle: ≈ 1.6 L/min L nozzle: ≈ 3.5 L/min
Max Effect Duration: 5 sec
Output Range: 6, 8 or 10 m (depending on the nozzle)
Enviromental

Humidity: 20% to 90%
Indoor or Outdoor: Both
Maximum Temperature: 50 °C
Minimum Temperature: -10 °C
Noise Level: 79 dB (at 3 m)
Mechanical

Height: 28 cm
Length: 41 cm
Max Tilt Angle: 45°
Mounting Surface: Floor / Rigging
Width: 30 cm
Power and Control

Control: DMX / RDM / Arm / Arm Override
Frequency: 50 / 60 Hz
Power: 395 W
Voltage Input: 220 – 250 VAC
Safety

Danger Zone: Maintain a free cylindrical output zone from each output of the Flameblazer. S nozzle radius 1.5 m, height 9 m / M nozzle radius 2 m, height 12 m / L nozzle: radius 2.5 m, height 15 m
Output Range: S Nozzle 6 m / M Nozzle 8 m / L Nozzle 10 m
Safety Zone: Always create a hazardous zone around the machine. • S nozzle radius 2 m, height 9 m / M nozzle radius 2.5 m, height 12 m / L nozzle radius 3.0 m, height 15 m
Other

Included Accessories: Flameblazer Nozzle L / Empty ADR Can 5 L (w/out Cap) / Flameblazer Custom Can Cap 5 L
Quantity Per Carton: 1

Downloads

User Guide Download
