GLP – JDC2 IP

Glp

The GLP JDC2 IP is a high-output hybrid strobe with pixel-mapped effects, DigiFX library, and NDI video stream playback – all in a rugged, motorized IP65 fixture built for the biggest shows.

Description

The GLP JDC2 IP is a groundbreaking hybrid strobe that raises the bar on brightness, control, and creativity. Designed for maximum impact, it combines brute-force output with elegant, digital versatility in a rugged IP65-rated body.

At the heart of the fixture is a newly integrated beam line powered by 84 high-performance 10 W LEDs, delivering ultra-intense flashes with razor-sharp, steep ramps for the most realistic strobe effects yet. With 12 individually controllable segments, it supports extended flash dynamics and includes over 100 built-in static and dynamic strobe patterns.

The JDC2 IP features a massive 1,025 cm² (159 in²) luminous surface, increasing visual solid angle and perceived brightness by up to 25%. Behind that surface, 1,728 RGB LEDs flood any environment in rich, saturated color — perfect for creating immersive atmospheres, especially when paired with haze. A black LED masking front ensures a clean look and reduces light spill from other sources.

Both color plates can be controlled separately in 12 or 24 segments, and an individually addressable pixel matrix unlocks stunning digital effects. Powered by a Dual Cortex CPU with built-in 3D graphic processing, the JDC2 IP features GLP DigiFX: a curated library of over 100 eye-catching pixel animations, ready to use without any external media server.

Need more? The fixture supports up to four external NDI streams via dual GigaBit EtherCon ports, letting you display real-time video content directly on the unit — no licenses, processors, or media servers required.

With motorized tilt (approx. 180°), the JDC2 IP offers precise directional control. Its rugged, sleek housing is built for indoor and outdoor use, and includes GLP’s iQ.Mesh interface and NFC Connect for fast setup and service.

Whether you’re designing a concert, festival, TV set, or installation, the JDC2 IP delivers a new level of creative freedom — without compromise.

Video

GLP JDC2 IP

Bigger. Better. Brighter.

Additional information

Light Source

Type: Beam: White Strobe LEDs, Plate: RGB LEDs
Count: Beam: 84, Plate: 1,728

Optical System

Output: Beam: up to 47,000 lm, Plate: up to 20,000 lm
Peak Luminous Intensity: 80 kcd
max. beam angle: Beam: 150°/49°, Plate: 160°/160°
Front Lens: 2 rectangular lenses, each 377 x 111 mm / 14.8 x 4.4 in

Dynamic Effects

Color Mixing: 2-way RGB, via DigiFX
Pattern Effects: Beam: up to 100 static or dynamic pattern effects
GLP DigiFX: Plate: up to 80 dynamic effects
Duration Channel: absolute or percentage
Insensity Effects: wide range of different Strobe Intensity Effects
Dimmer / Shutter: 0 – 100%, 16 bit
Preprogrammed Effects: via DigiFX: real time manipulation of speed, orientation, zoom, 4 special FX Channels

Control & Programming

Control Modes: M1: Dual Strobe, M2: Segment 1-1, M3: Segment 12-12, M4: Segment 12-24 (default), M5: JDC1 Spix Patch
High-Res Channels: Dimmer, Tilt, X/Y Position
Dimming Curves: linear, soft
Fan Modes: regulated, high, medium, low, minimum
Setting & Addressing: backlit graphic LCD, 4 Button Menu Navigation, DMX, RDM, GLP iQ.Mesh, 1 Scene Stand Alone
Other Control Options: Beam Pattern Effect Engine, Plate DigiFX Engine, Beam/Plate Intensity Flash Effects
Software Update: GLP iQ.Mesh

Connectors

Power Input: Neutrik powerCON TRUE1 In/Out
Signal Connection: Neutrik XLR 5-Pin In/Out, Gigabit etherCON ports In/Out (failsafe)

Construction

Housing Color: Black
Housing Material: high-impact flame-retardand thermoplastic, aluminum, steel metal plates
Protection Rating: IP65
Construction Features: Tilt-Lock-System, Alignment System, Head handles, built for optional accessories

Electrical Specifications

Power Input: 100 – 240 VAC / 50 – 60 Hz
Power Supply Unit: auto-ranging electronic switch-mode
max. Power (@ 230 V): 1,500 W

Installation

Mounting: 2 pairs of 1/4-turn locks, 2 eyelets for safety cable
Orientation: any
Location: indoor temporär, indoor permanent, outdoor temporär
min. distance to combustible materials: 0.1 m
min. distance to illuminated surfaces: 1.0 m

Movement

Tilt Angle: 184°, 16 bit

Shipping

Tourpack: 3-way, Omega Brackets

Thermal Specifications

Cooling: combined convection and forced air
Overheating Protection: automatic
min. Ambient Temperature: -10 °C / 14 °F
max. Ambient Temperature: 45 °C / 115 °F
Total Heat Dissipation: 5,150 BTU/hr

Dimensions & Weight

Height: 452 mm / 17.8 in
Height (head straight up): 354 mm / 13.94 in
Width (across yoke): 444 mm / 17.48 in
Depth: 230 mm / 9.06 in
Weight (net): 23.5 kg / 51.8 lbs
