GLP-impression-X4-XL-Front-RightGLP-impression-X4-XL-Front-Right

GLP – impression X4 XL

Glp

The GLP impression X4 XL delivers intense output from 55 RGBW LEDs and a 7–50° zoom. With individual pixel control, variable CTO, and a sleek baseless design, it’s ideal for creating eye-catching patterns and precise beam effects.

SKU: N/A Categories: , , , ,
Clear

Description

The incredible light output of 55 high-power RGBW LEDs (each rated at 15W), combined with a highly efficient 7–50° zoom lens, makes the impression X4 XL a standout in the lighting market.

The optics—taken from the acclaimed impression X4—deliver a well-defined beam with a hard edge at narrow zoom angles, while maintaining a smooth, homogenous output at wider angles. The fixture also features a sleek, baseless housing design.

RGBW colour mixing, variable CTO, and a finely tuned dimming curve come standard with the impression X4 XL. Each LED is individually controllable, allowing for a wide range of patterns to be displayed on the front lenses—including arrows, numbers, letters, and more—using either built-in or custom-designed presets.

Video

impression X4 XL Product Video

The incredible light output of 55 high power RGBW LEDs (each rated at 15W) coupled with the highly efficient 7 – 50° zoom lense make the impression X4 XL unique and unmatched in the lighting market.

Additional information

Light Source

Type: RGB LED
Count:55
Power: 15 W
Lifetime: 50,000 h
CRI (Ra): 69

Optical system

minimum Zoom (Deg): 7°
maximum Zoom (Deg.): 50°

Dynamic Effects

Color Mixing: RGBW
CTC: variable 2,500 – 10,000 K
Dimmer / Shutter: 0 – 100%, electronical

Control & Programming

Control Modes: Normal, Compressed, HighRes
Setting & Addressing: backlit graphic LCD

Connectors

Power Input: Neutrik powerCON TRUE1 In/Out
Signal Connection: Neutrik XLR 3-Pin In/Out, Neutrik XLR 5-Pin In/Out

Construction

Housing Color: Black, special colors on request

Electrical Specifications

Power Input: 100 – 240 VAC / 50 – 60 Hz
max. Power (@ 230 V): 800 W
Fuse: T12A 250V 6x32mm

Installation

Mounting: 2 eyelets for safety cable, M10 thread, adjustable rail for sideways truss installation (optional), removable baseplate with brackets for ratchet belt
Orientation: any

Movement

Pan Angle: 643°, 16 bit
Tilt Angle: 295°, 16 bit

Shipping

Single Fixture: carton
Tourpack: 2-way, Flightcase, Omega Brackets

Thermal Specifications

Overheating Protection: automatic
Total Heat Dissipation: 2,730 BTU/hr

Dimensions & Weight

Height (head straight up): 493 mm / 19.4 in
Width (across yoke): 493 mm / 19.4 in
Depth (head straight up): 293 mm / 9.4 in
Min. Center Distance: 550 mm / 21.7 in
Weight (net): 24 kg / 52.9 lbs

Downloads

User Guide Download
Data Sheet Download
