GLP – impression FR1

Glp

The GLP impression FR1 is a compact, fast-moving LED head with a 4°–35° zoom, RGBW colour control, and sharp beam options—perfect for tight setups and 3D beam effects.

SKU: GLP7686 Categories: , , , , , ,

Description

The GLP impression FR1 is a compact LED moving head designed for dynamic visual impact. It delivers a soft, narrow 4° pencil beam with lightning-fast movement and continuous pan rotation, ideal for creating eye-catching 3D multi-beam effects.

Its versatile optical system zooms from a tight 4° to a wide 35° soft wash. For sharper beam edges, the front diffuser can be removed, tightening the beam to 3.7°. At its core is a high-quality Osram RGBW Quad LED that produces vibrant saturated colours and tunable white light, with RGBW and CTO-based control options.

The FR1’s new micro Fresnel lens creates a smooth, round beam image with excellent visibility in plan view—perfect for TV and camera work. Housed in GLP’s signature baseless, ultra-compact design, the FR1 fits easily into the tightest rigging spaces for stages, TV studios, film sets, corporate events, and installations.

Video

impression FR1 Featurevideo EN

The new GLP impression FR1 is the latest compact LED moving head which offers a soft pencil beam and super fast movement and continuous pan rotation for amazing 3D multi beam designs.

Additional information

Light Source

Type: RGBW LED
Count: 1
Power: 60 W
Lifetime: 50,000 h
CRI (Ra): 80+
TLCI: 80+
Optical System

Output: 790 lm
Peak Luminous Intensity: 105 kcd
min. Zoom: 3.7°
max. Zoom: 35°
Zoom Ratio: 1:10
Front Lens: 100 mm / 3.94 in
Dynamic Effects

Color Mixing: RGBW
CTC: variable 2,500 – 10,000 K
Dimmer / Shutter: 0 – 100%, electronical
Control & Programming

DMX Channels: 16
Control Modes: 1
High-Res Channels: Intensity, Pan, Tilt
Dimming Curves: linear, soft
Fan Modes: regulated, high, medium, low
Setting & Addressing: backlit graphic LCD, 4 Button Menu Navigation, DMX, RDM
Connectors

Power Input: Neutrik powerCON TRUE1 In/Out
Signal Connection: Neutrik XLR 5-Pin In/Out
Construction

Housing Color: Black, White
Housing Material: high-impact flame-retardand thermoplastic, aluminum, steel metal plates
Protection Rating: IP20
Construction Features: baseless Design
Electrical Specifications

Power Input: 100 – 240 VAC / 50 – 60 Hz
Power Supply Unit: auto-ranging electronic switch-mode
max. Power (@ 230 V): 85 W
Fuse: T5A 20mm
max. number of devices on one power line: at 230 V: 40, at 110 V: 20
EEC: E
EEI: 1.193
Ec: 68
Installation

Mounting: 1 eyelet for safety cable, M10 thread, rubber feet
Orientation: any
Location: trocken
min. distance to combustible materials: 0.1 m
min. distance to illuminated surfaces: 1.0 m
Movement

Pan Angle: 629° continuous
Tilt Angle: 210°
Shipping

Single Fixture: carton
Tourpack: 6-way, 12-way, Flightcase
Thermal Specifications

Cooling: combined convection and forced air
Overheating Protection: automatic
min. Ambient Temperature: 5 °C / 40 °F
max. Ambient Temperature: 45 °C / 113 °F
Total Heat Dissipation: 290 BTU/h
Dimensions & Weight

Height: 264 mm / 10.4 in
Width: 190 mm / 7.5 in
Depth: 140 mm / 5.5 in
Weight (net): 4 kg / 8.8 lbs
