ETC – ColorSource PAR V Zoom

ETC

A 17-41 degree manual zoom fixture. balanced mix of red, green, blue, indigo, and lime LEDs, impressively bright, change between spot and wash with a twist of the wrist.

SKU: ETC7421A1210 Categories: , , ,

Description

ColorSource PAR V Zoom is an LED luminaire crafted by lighting experts with a proven history of quality. The manual zoom eliminates the need for additional diffusion and lets you change between spot and wash with a twist of the wrist. With a balanced mix of red, green, blue, indigo, and lime LEDs, and impressive brightness, this will become your new go-to fixture. Add in the features available on all ColorSource V fixtures – Multiverse® wireless, NFC configuration, and next-level brightness – and you have another flexible, workhorse fixture from ETC.

Features

  • Five-color array (red, green, blue, indigo, and lime)
  • Manual 17–41 degree zoom
  • Simple user interface with seven-segment display
  • powerCON® TRUE1® TOP connector
  • DMX/RDM in and thru (5-pin XLR)
  • Multiverse wireless DMX/RDM
  • NFC (near field communication) configuration
  • LED droop compensation
  • Optically calibrated
  • Tour-ready, aluminum housing

Video

ETC ColorSource PAR V Zoom

ColorSource PAR V Zoom is an LED luminaire crafted by lighting experts with a proven history of quality. The 17-41 degree manual zoom eliminates the need for additional diffusion and lets you change between spot and wash with a twist of the wrist. With a balanced mix of red, green, blue, indigo, and lime LEDs, and extreme brightness, this will become your new go-to fixture. You can expect the same feature set as the other fixtures in the ColorSource V family including NFC configuration from your mobile device, and an extra 10 universes of control with Multiverse wireless DMX/RDM.

Aplications

  • Theatres and performance spaces
  • Houses of worship
  • Universities and schools
  • Hospitality
  • Retail
  • Exhibition centers
  • Meeting rooms
  • Clubs
  • Cafetoriums

Additional information

Source

LED details: 34 Lumileds LUXEON® C LEDs
Max lumens: 5007
Lumens per watt: 33.4
L70 rating (hours to 70% output)*: 54,000 hours
*Note: All measurements are for 120 V, 60 Hz. Results may vary in different regions.

Color

Colors used: Red, Green, Blue, Indigo, Lime
Color temperature range: Color mixing
Calibrated array: Yes
Red shift: No

Optical

Beam angle range: 17°–41°
Gate size: N/A
Aperture size: 190 mm (7.48 in)
Pattern projection: No
Pattern size: N/A
Camera flicker control/Hz range:
5,000 Hz (default) and 25,000 Hz (via RDM)

Control

Input method: 5-Pin XLR, Multiverse wireless, and NFC
Protocols: DMX-512, RDM, City Theatrical Multiverse, NFC
Modes (footprint): 5 modes, see page 6
RDM configuration: Yes
UI type: Seven-segment display, three-button interface
Local control: Yes
Onboard presets: Yes (12)
Onboard sequences: Yes (5)
Onboard effects: No
FixtureLink: Yes
Notes: 15-bit virtual dimming engine

Wireless

Band: 2.400–2.480 GHz
Range: 100 m indoors, 500 m line of sight (subject to conditions)
Max receivers:
DMX: No limit
RDM: Varies by transmitter used
Multiverse SHoW Baby®: 585
Multiverse Transmitter: 5,000
Broadcast power: 100 mW

Electrical

Voltage range: 100–240 VAC 50/60 Hz
Input method: powerCON TRUE1 TOP power in and thru
Inrush (first half-cycle):
120 V: 31 A
240 V: 66 A
Fixtures per circuit on standard R20 breaker:
6 (link up to 5 via Power Thru connector)*
Note: TRUE1 connector rated for
20 A (120 V / 60 Hz) and
16 A (240 V / 50 Hz)
Wattage (typical):
120 V: 150 W
230 V: 148 W
Current draw:
120 V: 1.27 A
230 V: 0.70 A

Thermal

Ambient operating temp: 0°C–40° C (32°F–104° F)
Fan (controllable): Yes (yes)
Droop compensation: Yes
Average dB: TBD dBA
BTUs/hour (120 V): 512

Physical

Materials: Cast and extruded aluminum
Color options: Black, white, silver, or custom color
Mounting options: Yoke
IP rating: IP20
Weight: 4.45 kg (9.8 lb)
Included accessories: Yoke, power cable

Warranty

Fixture: 5 years
LED array: 10 years
