Elation – SŌL IV Blinder

Elation

Versitile blinder with a broad range of tuneable colour, variable strobe, red shift emulation and 16-bit dimming.

SKU: ELA1236300108 Categories: , , ,

Description

Introducing the SŌL IV BLINDER, the most versatile addition to the SŌL Series yet, featuring a grid of four fixtures in a single modular housing. Like the SŌL I and SŌL II, the SŌL IV offers the same cutting-edge technology and powerful LED engine but with even greater creative potential through its multi-fixture design.

The SŌL IV BLINDER can be used as a standalone fixture or interconnected in endless configurations with additional SŌL IV units, as well as the SŌL I and SŌL II models. This flexibility allows lighting professionals to craft expansive arrays, intricate shapes, and dynamic effects that adapt to any stage or event setup.

With the same 350W RGB+Lime+Amber+White LED engine, 93+ CRI, and IP65-rated durability, the SŌL IV delivers unmatched brightness, color fidelity, and performance. Whether you’re looking for an impactful standalone solution or a fixture that integrates seamlessly into a larger lighting design, the SŌL IV BLINDER provides the ultimate canvas for your creativity.

Illuminate your vision with the boundless possibilities of the SŌL IV BLINDER – the next step in redefining stage lighting innovation.

Features

  • 4x 350W RGBLAW LED
  • 59,830 Total Fixture Lumen Output (Sphere)
  • 46° Beam Angle
  • Simple ‘Array Mode’ Addressing System
  • Individual Pan Adjustment with Lock
  • Dim-to-Warm/ Red Shift Emulation
  • High Output Blinder Mode or Constant Output Mode Options
  • Unique Horizonal and Vertical Array Rigging Method (Compatible with SŌL II, SŌL I Blinder Frame, Pulse Panel, SIX+ BAR and PULSE BAR Interconnect)
  • IP65 Rated

Additional information

Source

4 X 350W RGBLAW LED
30,000 Hour Average LED Life*
*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.

Photometric Data

Total Lumen Output
59.830 (Integrating Sphere)
CRI TBA

Compound Lens

Beam Angle: 46°
Field Angle: 85°

No Lens

Beam Angle: 52°
Field Angle: 95°

Effects

Variable Strobe Rate: 1- 20Hz
Dim-to-Warm/ Red Shift Emulation
Variable 16-bit Dimming Modes and Curves
High Output Blinder Mode or Constant Output Mode Options

Colour

RGBLAW Color Array
CMY Emulation
Variable CCT 1,800K – 8,500K
Virtual Gel Swatch Book

Contro / Connections

24 DMX Channel Modes (1ch, 2ch, 4ch, 2ch, 4ch, 8ch, 3ch, 5ch, 9ch, 4ch, 8ch, 16ch, 6ch, 12ch, 24ch, 7ch, 10ch, 16ch, 40ch, 69ch, 28ch, 45ch, 28ch & 45ch)
Simple 'Array Mode' Addressing System
Manual and DMX Controlled Dimmer and Color
4 Button Control Panel, LED Display
Aria x2 Wireless Device Management
RDM (Remote Device Management)
IP65 5pin DMX Cable In/Out
IP65 Locking Power Cable In

Size / Weight

Length: 240 mm (9.4”)
Width: 420 mm (16.54”)
Vertical Height: 471 mm (18.6”)
Weight (Fixture Only): 19 kg (41.9 lbs)

Electrical / Thermal

AC 100-240V – 50/60Hz
1300W Max Power Consumption
-15°C to 45°C (5°F to 113°F)
BTU/hr (+/- 10%) 4262.5

Included Items

Removable Fixture Yoke / Omega Bracket
2x Fixture Interconnect Splices
IP65 Locking Power Cable

Downloads

Data Sheet Download
User Guide Download
