Powered by Powerline, Power-over-Ethernet or AC/DC adapte
Fits 4-gang standard US ANSI/NEMA OS-1 electrical box, a 4-gang wall box or optional S-MOUNT enclosure
Additional information
Weight
0.53 kg
Channels
Two intercom channels (Selectable) Program Audio (Assignable from Main Station
Connectors
Intercom Line: (2) 3-pin XLR–M–F Intercom Line Pin Function: Pin 1: Ground Pin 2: +30V DC and Audio Pin 3: -30V DC and Audio Headset: 4-pin XLR–M & 2.5mm TRS jack USB: Micro AB
Microphone Pre-amplifier
Headset Mic Impedance: 200Ω (Dynamic) Headset Mic Voltage: 1.7V (Electret selectable) Limiter: +23dB The following specified for a route to four-wire output at 0dBu out: Mic Gain: 60dB (Dynamic), 45dB (Electret) Frequency Response: 300Hz – 10 kHz ±3dB, contoured for Intelligibility
Headphone Amplifier
Load Impedance: >32Ω Output Level: +12dBu before clipping Sidetone: -12dBu (selectable) The following specified for a route from a four-wire input at 0dBu in Max Gain: 0dB Frequency Response: 40Hz – 10kHz ±3dB Distortion: <0.1% THD @ 1kHz Noise: -65dBu Headphone Limiter: 0dBu (selectable)
