Clearcom – BP410

Clearcom

2-Channel 2.4GHz Wireless Beltpack

SKU: CLECZ-BP410 Categories: , , ,

Description

The industry’s lightest weight beltpack, at only 7.4 ounces (0.21 kg).

Rugged, over-mold, reinforced casing and long-lasting keypads with no mechanical switch. Internal antennas inside the beltpack provide extra protection and durability. Buttons are completely sealed to dramatically enhance the life of the beltpack by keeping dirt and moisture out and preventing mechanical failures.

Provide up to 12 hours of beltpack operation with each charge.

Feature Quick View

  • 2-Channel 2.4GHz Wireless Beltpack
  • Two-channel operation
  • 2.4GHz license-free operation
  • Up to 15 beltpacks and/or all-in-one handsets on a single system
  • 7kHz wideband audio
  • Single or dual-channel operation
  • Up to 12 hours of battery life
  • Light-weight, compact design, ergonomic design
  • Rugged and reliable

Additional information

Weight 0.21 kg
Audio

Channels: 2 audio channels Frequency Range: 2400 MHz – 2483.5 MHz Frequency Response: 200 Hz – 7 kHz Antenna: Internal, horizontal/vertical diversity Headset Connector: 4-pin, mini-DIN Microphone: Electret Headset Output: 160mW into 32 Ohms System Distortion: <2% Controls: Power, Volume-Up, Volume-Down, A, B, ISO Indicators: Dual-color LED (red/green) Battery Requirements: 3.6V lithium-ion Battery Life: Up to 12 hours

Antenna

Internal, Horizontal/Vertical diversity

Transmitter

Type: Frequency Hopping, Spread Spectrum (FHSS) Transmit Power: 100mW burst Modes: Momentary or Latch Type: Gaussian filtered FSK, TDMA Frequency Stability: 13 ppm Harmonics/Spurious: Exceeds FCC and ETSI specifications

Receiver

Type: Frequency Hopping, Spread Spectrum (FHSS) RF Sensitivity: <-90dBm w 10-3 BER Frequency Stability: 13 ppm Distortion: <2%

Environmental

32°F to +122°F (0°C to +50°C)

Dimensions

2.25 x 4.5 x 1 in (57.2 x 114.3 x 25.4 mm) (HxWxD)

Downloads

User Guide Download
Data sheet Download
