Claypaky – Ultimo Sharpy

Claypaky

Ultimo Sharpy is built for the rig: compact yet powerful, rugged yet precise. Its specs are tailored for professionals who need maximum performance, minimal downtime, and total confidence.

SKU: CLACD3040 Categories: , , ,

Description

Meet Ultimo Sharpy, the next-gen beam moving head that packs serious power into a sleek, lightweight design.

IP66-rated and built for extreme conditions, it delivers fast motion, bold colors, and stunning aerial effects anywhere the show takes you.

Features

Compact Power, Massive Output

100,000 lux at 20 meters (over 9,300 fc at 65 ft). Sharp, halo-free beam in a 19.5 kg, less than 43 pounds, body. Built to perform and make a big impact from a small footprint.

Low-Noise Mode

This new firmware update brings quieter, more controlled operation to Ultimo Sharpy, reducing sound levels by 7 dB while maintaining 90 % of the original light output.

IP66-Rated. Ready for Anything.

Rain? Dust? Rough tours? No problem. Ultimo Sharpy is built to shine outdoors, under pressure, and in the harshest setups.

Unleash Your Creative Freedom

True and ultrafast CMY mixing, dual prisms, frost, gobos: Ultimo Sharpy has everything you need to craft bold mid-air looks and seamless transitions.

Blazing-Fast. Effortlessly Precise

Ultra-fast tilt. Infinite pan. Designed to keep pace with beat drops, live cues, and precision timecode shows, without limits.

Eco-Conscious, Pro-Ready

Up to 6,000 hours of OSRAM HID lamp life, smart dimming, recyclable components, and reduced mercury. Smarter for you, better for the planet.

Perfect Dimming, Flicker-Free

Smooth, cinematic fades and flicker-free output perfect for stage, studio, and broadcast environments.

Video

Claypaky Ultimo Sharpy

Meet the new benchmark in compact beam lighting: Ultimo Sharpy. Building on the legacy of the original Sharpy, this next-generation IP66-rated beam moving head is brighter, faster, and tougher than ever. At the heart of Ultimo Sharpy lies a brand-new 250W Ultra-High Performance short-arc lamp, designed for maximum output and sustainability.

Additional information

Light Source

Source type: Short-arc High Intensity Discharge (HID) lamp
Colour Temperature: 7200K
CRI: Up to 74
Lamp life expectancy: 6000 hrs L70
*It may vary depending on various factors, as type of use and environment
Photometric Data

Zoom range: 2° beam angle with focus lens
Lumen output: 11.200 (Integrating Sphere)
Front lens diameter: 140 mm
Optical system: High efficiency
Noise Level

Auto: 50.0 dBA
Low noise: 43.0 dBA
Control and Connections

Personalities: 3 personalities with 27 / 16 / 27 control channels
Protocols: DMX, Art-Net, RDM, sACN, CRMX (Lumen Radio)
Connectors:
Locking 5 pin XLR IN/OUT
Ethernet port: RJ45 IN/OUT
Power connector: PowerCon True1 IN/OUT
Web Server: Built In
CloudIO: Fully compatible
Dynamic Effects

Colours:
Fixed color wheel with 14 dichroic colors – True CMY color mixing system
Gobos:
1 Static Gobo Wheel with 17 gobos
Frost:
1 Linear heavy frost 10° for wash effect
Rotating Effects:
1 8 facet prism with rotation in both directions at variable speed
1 6 facet linear prism with rotation in both directions at variable speed
Movement:
Tilt: 275°
Pan: infinite rotation
Accuracy: Resolution ± 0.46° (±0° 27' 36")
Range: 0,92° (0° 55' 12")
Absolute position
Mechanical Pan/Tilt lock for safe transportation and maintenance
Dimmer/Shutter:
High resolution mechaical dimmer – 24 bit, 5 curves
Ultra-smooth electronic dimmer with high resolution fades
Special feature:
Sharpy emulation mode for plug-and-play legacy compatibility
Hardware and Software

Long life self-charging battery
Display Graphic LCD backlit b/w display
Firmware upload from another fixture
Firmware upgrade via Web Server
Diagnostic
DMX monitoring
Remote access through RDM
Housing

Aluminum and steel structure with plastic covers
Two side handles for transportation
IP66 protection rate
Working Position

Working in any position
Hanging system: with fast-lock omega clamps (1/4 turn) on the base
Optional safety chain
Electrical

Operating Voltage: 100-240V, 50/60 Hz
Power Supply: Electronic auto range with active PFC
Max Power consumption: 460W (4.6A)
Thermal Specification

Max ambient temperature: 45°C (113°F)
Min ambient temperature: -20°C (-4°F)
Max temperature of the external surface: 90°C (194°F)
Total heat dissipation: 1600 BTU/hr ±10% / 1700 kJ/hr ±10%
Safety Specs

Minimum distance of illuminated objects 13 meters (42' 8”)
Minimum distance from flammable materials 0.2 meters (8”)
Thermally protected power supply (overheating and cooling failure)
Forced ventilation with axial fans
F6.3A 250V 5×20 mm – External mains fuse
5A 250V 5×20 mm – External mains
Compliance

CE Marking (in conformity to the following):
2104/53/EU Radio Equipment Directive (RED)
2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
2009/125/EC EcoDesign requirements for Energy related Products (ErP)
UKCA: conforms to UK Regulations:
S.I. 2017 N. 1206
S.I. 2012 N. 3032
S.I. 2021 N. 745
cMETus Listed:
UL 1573:2003
CSA C22.2 N. 166: 2015
Packing

Carton box + Polystyrene
Carton box + Foam shell (4 positions)
Flight case + Foam shell (4 positions)
Weight - Size

Weight: 19.48 Kg (42.95 lbs)
Base dimensions: 365 x 251 mm – 14.4 x 9.9 In
Height with vertical head (h): 538 mm – 21.2 In
Distance between two fixtures: 376 mm
Accessories

Omega clamps: 2×183102/805 (included)
ETL Power cord: CAB02B/802 (included)
*Cord 1.5 m (bare end with IP65 PowerConTrue1 conn.)
CRMX antenna extension: ANT004 (optional)
Flight case (4 positions): CF1048F (optional)
Foam shell: F21358/001 (optional)
Safety Chain: 105041/001 (optional)
Clamp: C21070 (optional)
