Chauvet Professional - STRIKE Array 2C front right of lighting fixture showing yoke adjustmentChauvet Professional - STRIKE Array 2C front right of lighting fixture showing yoke adjustment

Chauvet Professional – STRIKE Array 2C

Chauvet Professional

An IP65-rated audience blinder featuring two independently focusable pods with RGBA-WW LEDs for a full color spectrum, variable white temperatures, and smooth, tungsten-emulating dimming.

Perfect for broadcast, concert, and festival applications requiring a scalable, weather-resistant blinder with exceptional color rendering and advanced dimming control.

Features

  • Achieves superior color rendering with a high CRI of 94.4, perfect for broadcast applications.
  • Features an IP65-rated housing for dependable, all-weather use at festivals and outdoor events.
  • Provides a classic tungsten look with a Red Shift effect that warms color as it dims.
  • Connect multiple units effortlessly with a tool-free interlocking system for building large arrays.
  • Supports DMX, RDM, Art-Net, and sACN protocols for flexible professional control integration.
  • Allows for precise directional control with two pods that feature independent pan and tilt articulation.
SKU: STRIKEARRAY2C Categories: , , ,

Description

STRIKE Array 2C is an IP65-rated audience blinder with two independently focusable pods. Intense RGBA-WW LED output delivers a full range of color as well as a wide choice of white color temperatures with exceptional color rendering. Offering the industry leading low end dimming performance our STRIKE Array fixtures are known for as well as Red Shift that warms the color temperature of the light as it dims to emulate a classic tungsten look. Variable PWM and high CRI make this the ideal blinder for broadcast applications. Its proprietary Tool-Free interlocking system enables STRIKE Array 2C to be easily interconnected with multiple Array units for scalable configurations. Omega-Bracket locks are also installed on both the yoke and the rear of the fixture to streamline the truss mounting process.

Features

IP65 All-Weather Blinder

An intense 2-pod color blinder and strobe rated IP65 for reliable use in any environment.

Full Spectrum Color

Provides a full range of color and an excellent rendition of any color temperature of white.

Incandescent Red Shift

Emulates the warm dimming curve of traditional incandescent fixtures perfectly.

Individual Pod Articulation

Each head offers individual pan or tilt adjustment for directional control of the light output.

Interlocking Array System

An innovative system allows you to easily connect multiple STRIKE Array family fixtures together.

Versatile Rigging Options

Multiple mounting locations and a repositionable yoke with quarter-turn adaptors provide creative and convenient rigging.

Independent Pod Control

Manage each pod and its strobe functionality independently for high-impact effects on the fly.

Smooth 18-Bit Dimming

Ultra-smooth 18-bit dimming curves and speeds complement any lighting scheme.

Video

STRIKE Array C + STRIKE Bolt 1C: IP65 Full-Color Blinders and Strobes FTW by CHAUVET Professional

Level Up • Power Up • Stack Up • FTW • Now You’ve Got ALL the CODES to Raise Your Game with IP65 Full-Color Blinders and Strobes Built FOR THE WILD!

What’s Included

  • STRIKE Array 2C
  • Seetronic Powerkon IP65
  • Omega bracket with mounting hardware

Additional information

Optical

Light Source: 134 LEDs (56 quad-color RGBA, 78 WW) 2.7 to 4.32 W, (871 mA), 50,000 hours life expectancy.
Color Temperature (range): 2800 to 6500 K
Color Temperature (at full): 6528 K
CRI: 94.4
CRI (@3200K): 94.4
Beam Angle: 59.1°
Field Angle: 102.1°
Lumens: 25,917
Illuminance (total): 979 lux @ 5 m
Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz
Connections

Power Connection: Edison (Local) plug to Seetronic Powerkon IP65: Power Input
Seetronic Powerkon IP65: Power Output
Seetronic Powerkon IP65: Data Connectors
5-pin Seetronic IP65 XLR or Seetronic IP65 etherCON
Cable Length (power): 5 ft (1.5 m)
Software Update: USB-C
Certifications / Qualifications

Certifications: CE, MET, FCC, ETL, cULus
IP Rating: IP65, outdoor/wet, with pressure equalizing M12 GORE valve
Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
Dynamic Effects

Dimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0 to 30 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Dim Curves: 4
Built-in Automated Programs: Yes
Construction / Physical

Dimensions: 19.13 x 7.45 x 10.37 in (486 x 189.3 x 263.5 mm)
Weight: 20.6 lb (9.4 kg)
Exterior Color: Black
Housing Material: Aluminum alloy
Control

Control Protocol
Art-Net, sACN, DMX, RDM
Modes/Personalities
10 personalities (1ch, 3ch, 5ch, 7ch, 10ch, 12ch1, 12ch2 13ch, 16ch, HSV)
Electrical

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 2 units @ 120 V; 4 units @ 208 V; 4 units @ 230 V
Power and Current: 600 W, 5.000 A @ 120 V, 60 Hz
Power and Current: 583 W, 2.780 A @ 208 V, 60 Hz
Power and Current: 581 W, 2.491 A @ 230 V, 50 Hz

Downloads

Data Sheet Download
User Guide Download
