Chauvet Professional – Rogue Outcast 2 Beam

Chauvet Professional

A lightweight, IP65-rated moving head beam fixture that harnesses a powerful 300W lamp to project an intensely bright, tight beam with multifaceted aerial looks from split colors, gobos, and rotating prisms.

Suited for both indoor and outdoor productions, including tours, festivals, and large-scale events that demand a powerful, weather-resistant fixture for creating cutting aerial beam effects.

Features

  • Features a 300W Ushio lamp projecting a razor-sharp 0.8° beam for intense, focused aerial effects.
  • Built with a lightweight, IP65-rated alloy housing for reliable performance in any weather condition.
  • Offers independently controlled and layerable 5-facet linear and 8-facet round prisms for dynamic visuals.
  • Expands creative options with a 17-pattern static gobo wheel and a 14-color wheel for split-color effects.
  • Includes a frost filter to create an even light distribution for versatile soft-edged wash looks.
  • Supports both DMX and RDM protocols for comprehensive remote control and fixture management.
SKU: ROGUEOUTCAST2BEAM Categories: , , ,

Description

Rogue Outcast 2 Beam projects intensely bright and tight beams from a lightweight IP65 moving head designed to harness the power of its 300W 8000K lamp to slice through atmospherics and outshine any other effect. Aerial looks are sharp and multifaceted with split colors, stunning gobos, layerable rotating prisms and precision focus. Apply frost for even light distribution. Reduce maintenance with a durable alloy body built to withstand the elements, inside or out.

Features

High-Powered Beam Fixture

A fully featured fixture powered by a long-lasting Ushio 300W lamp with an 8,000-hour life expectancy.

IP65 Rated Housing

Features a lightweight aluminum and magnesium housing with an IP65 rating for protection against the elements.

Dual Layerable Prisms

Create stunning visual impact with individually controllable and layerable 5-facet linear and 8-facet round prisms.

Frost Filter

Includes a frost effect for producing an even light distribution and soft-edge looks.

Tight Beam Angle

Produces a razor-sharp 0.8° narrow beam for highly focused aerial effects with no field spill.

Static Gobo Wheel

Offers a wide array of 17 static gobos for creating massive visual effects.

Flexible Protocol Control

Supports both DMX and RDM protocols for comprehensive remote control and management.

Professional Power Input

Equipped with a True 1 compatible power input for secure and reliable connections.

Onboard OLED Display

Features an easy-to-read OLED display with a simple menu for effortless fixture setup.

Versatile DMX Profiles

Provides both simple and complex DMX channel profiles to suit any programming style.

USB-C Software Port

Allows for easy software uploads and updates via a convenient USB-C port.

What’s Included

  • Rogue Outcast 2 Hybrid
  • Seetronic Powerkon IP65 power cord
  • 2 Omega brackets with mounting hardware

Additional information

Optical

Light Source: 300W NSL Ushio lamp, 8000 K (color temp), 8,000 hours life expectancy
Color Temperature (at full): 7353 K
Front lens diameter: 160 mm
CRI: 75.5
Beam Angle: 0.8°
Field Angle: 1.6°
Cutoff Angle: 2°
Lumens – Output: 29,130
Illuminance (total): 204,855 lux @ 15 m
Construction / Physical

Dimensions: 14.41 x 9.61 x 22.6 in (366 x 244 x 574 mm)
Weight: 45.19 lb (20.5 kg)
Exterior Color: Black
Housing Material: Aluminum/Magnesium diecast
Controls

Control Protocol: DMX, RDM
DMX Channels: 16 or 18
Modes/Personalities: 2 personalities (16, 18)
Certification and Qualifications

Certifications: CE, MET, UKCA
IP Rating: IP65, temporary outdoor/ wet, with pressure equalizing M12 GORE valve
Temperature (Ambient): -14 °F to 113 °F (-10 °C to 45 °C)
Maximum Exterior Surface Temperature (Tc): 80° C / 176° F
Maximum Ambient Temperature (Ta): 45° C / 113° F
Dynamic Effects

Pan and Tilt: 540°/260°
Pan and Tilt Ranges: 540°, 360°, 180° pan/260°, 180°, 90° tilt
Colors: 14 + white, split colors, continuous scroll at variable speeds
Gobos: 17 + open (17 metal), 17 static, continuous scroll at variable speeds; size: 106 mm (outside), 6 mm (image), 0.6 – 0.8 mm (max. thickness)
Dimmer: Electronic
Shutter/Strobe: Motorized
Focus: Motorized
Frost: Motorized
Prism:
Detail: 5 Facets, motorized, rotating
Detail 2: 8 Facets, motorized, rotating
Move-in-Black: Yes
Connections

Power Connection: Edison plug to Seetronic Powerkon IP65
Power Input: Seetronic Powerkon IP65
Data Connectors: 5-pin IP rated
Cable Length (power): 5 ft (1.5 m)
Electrical

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 413 W, 3.51 A @ 120 V, 60 Hz
Power and Current: 403 W, 2.01 A @ 208 V, 60 Hz
Power and Current: 404 W, 1.82 A @ 230 V, 50 Hz
Compatible Accessories

Clamps
IP65 5 pin DMX Cables
IP65 PowerKon Extension cables
Flight Case
