Chauvet Professional - Ovation Rêve F-3 IP Frotn rightChauvet Professional - Ovation Rêve F-3 IP Frotn right

Chauvet Professional – Ovation Rêve F-3 IP

Chauvet Professional

A motorized, full-spectrum RGBAM fresnel that delivers soft, controllable washes with silent operation and an extended zoom range for impressive reach.

Perfectly suited for camera-sensitive environments like theaters, houses of worship, and television/film sets that demand versatile, high-quality, and silent wash lighting.

Fetaures

  • Delivers superior color rendering with a full-spectrum RGBAM LED engine and an impressive 96 CRI.
  • Provides an extended motorized zoom range from 10.9° to 66.5° for impressive reach and coverage.
  • Features linear color temperature control from 2800 K to 8000 K with +/- green adjustment.
  • On-board control dials offer quick adjustments, while its silent cooling is ideal for studio use.
  • Delivers flicker-free video performance using adjustable PWM and exceptionally smooth 18-bit dimming.
  • An innovative adjustable yoke allows for versatile mounting and positioning in low-clearance areas.
SKU: OVATIONREVEF3IP Categories: , , ,

Description

Ovation Rêve F-3 is a motorized fresnel incorporating our full spectrum (RGBAM) Rêve light engine. A welcome solution for applications and markets in need of soft controllable washes, Rêve F-3 features virtually silent operation, easy on-board control dials, and an innovative adjustable yoke that allows it to be mounted in low clearance areas. Featuring an optical system designed to answer the call for longer throws with an extended zoom range that can narrow from 60 degrees all the way down to 10 degrees in order to achieve impressive reach. A versatile lighting instrument at home in theaters, houses of worship, on TV and Film sets, as well as the rental and production world. Flawlessly smooth dimming, +/- green adjustment, linear CCT and adjustable Pulse Width Modulation ensure performance that looks as good on camera as it does live.

Features

Full Spectrum LED Fresnel

Provides high-quality, full-spectrum light ideal for theatre, film, and production environments.

On-Board Control Dials

Easily adjust multiple parameters directly on the fixture using three intuitive control dials.

Adjustable Color Temperature

Access a wide range of linear color temperature presets from 2800 K to 8000 K with high color rendering.

Virtual Color Wheel

Replicate popular gel colors digitally with the integrated virtual color wheel.

Precise Color Control

Fine-tune your look with plus/minus green adjustment and emulated red-shift via DMX or on-board controls.

Remote Device Management

RDM capability allows for remote addressing and configuration for added flexibility.

Flicker-Free Operation

Adjust the Pulse Width Modulation (PWM) to eliminate on-camera flicker for clean video recording.

Silent Operation

The virtually silent cooling system is perfect for use in noise-sensitive studio and theatre applications.

High-Resolution Dimming

Achieve exceptionally smooth fades with ultra-smooth 18-bit dimming curves to complement any lighting scheme.

Adjustable Mounting Yoke

An innovative, adjustable yoke allows for easy mounting and positioning in low clearance areas.

USB Software Updates

Keep the fixture’s software current with easy updates via the built-in USB port.

What’s Included

  • Ovation Reve F-3 IP
  • Seetronic Powerkon power cord
  • Gel frame
  • (1) 140mm Omega bracket with mounting hardware

Additional information

Optical

Light Source: 126 LEDs (22 red, 14 green, 16 blue, 6 royal blue, 28 amber, 40 mint) 5.8 to 8 W, (1.82 A) 50,000 hours life expectancy.
Color Temperature (range): 2800 to 8000 K
Color Temperature (at full): 5249 K
Front lens diameters: 210.8 mm
CRI: 96
Beam Angle: 10.9° to 66.5°
Field Angle: 19.3° to 88.5°
Cutoff Angle: 26.2° to 97.3°
Zoom Range: 10.9° to 97.3°
Lumens (narrow): 6179 lm
Lumens (wide): 14302 lm
Lumens (50%): 10330 lm
Illuminance:
Illuminance (narrow): 5375 lux @ 5 m
Illuminance (wide): 539 lux @ 5 m
Illuminance (50%): 1858 lux @ 5 m
Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
Control

Control Protocol: DMX, RDM
DMX Channels: 1, 5, 6, 8, 12, 14ch1, 14ch2, or 18
Modes/Personalities: 8 personalities (1, 5, 6, 8, 12, 14ch1, 14ch2, or 18)
Electrical

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 2 units @ 120 V; 4 units @ 208 V; 5 units @ 230 V
Power and Current: 528 W, 4.39 A @ 120 V, 60 Hz
Power and Current: 517 W, 2.52 A @ 208 V, 60 Hz
Power and Current: 513 W, 2.22 A @ 230 V, 50 Hz
Dynamic Effects

Dimmer: Electronic
Shutter/Strobe: Electronic
Zoom: Motorized
Strobe Rate: 0 to 30 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Dim Curves: 4
Built-in Automated Programs: Yes
Construction / Physical

Dimensions: 15 x 13.5 x 15.7 in (381.4 x 342 x 399.3 mm)
Weight: 26.2 lb (11.9kg)
Exterior Color: Black
Housing Material: Aluminum die-cast
Accessory Holder/Gel Frame Size: 7.8 in (198 mm)
Connections

Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
Power Input: Seetronic Powerkon IP65
Power Output: Seetronic Powerkon IP65
Data Connectors: 3- and 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
Software Connection: USB
Certifications / Qualifications

Certifications: CE, MET, FCC
IP Rating: IP20, dry location
Noise Levels:
Noise Level (Idle): 4.1 dB(A) @ 1 m
Noise Level (Auto): 37.2 dB(A) @ 1 m
Noise Level (On): 39.1 dB(A) @ 1 m
Noise Level (Off): 6.5 dB(A) @ 1 m
Noise Level (Silent): 35.1 dB(A) @ 1 m
Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

Downloads

Data Sheet Download
User Guide Download
