Chauvet Professional – Ovation Rêve E-3

Chauvet Professional

The Ovation Rêve E-3 is a high-output, multi-color LED ellipsoidal that fuses a full spectrum of saturated colors with a range of precisely tunable whites, complete with emulated red-shift and virtually silent operation.

Ideal for theatrical productions, broadcast studios, houses of worship, and any application requiring silent operation with both vibrant, full-color rendering and high-quality white light from a single fixture.

Features

  • Offers a tunable CCT range from 2800 K to 8000 K with high CRI.
  • Includes emulated red-shift and +/- green adjustment for precise white light control.
  • Engineered for virtually silent operation with fan-off modes for noise-sensitive environments.
  • Achieves seamless fades and transitions with ultra-smooth 18-bit dimming curves.
  • Ensures flicker-free operation on camera with adjustable Pulse Width Modulation.
  • Features an innovative, adjustable yoke for easy mounting in low-clearance situations.
SKU: OVATIONREVEE3 Categories: , , ,
Clear

Description

Ovation Rêve E-3 is the brightest, multi-color LED ellipsoidal that also has the capability of producing perfectly tunable whites. It’s a new kind of epic story-telling machine that fuses the best of both worlds into one totally reimagined LED light source. Color Temperature presets ranging from 2800K to 8000K maintain outstanding brightness and a high quality of light, with an emulated “red shift” for a tungsten feel. Ovation Rêve E-3 also features several dimming curves, a virtually silent operation with fan-off modes, and a series of technician-friendly features such as an innovative, adjustable yoke that makes mounting in low clearance situations a breeze. With Ovation Rêve E-3 you can seamlessly transition from captivating a wide range of saturated colors in class-leading output to distinct whites with +/- green adjustments using one fixture. No ifs, or buts. Simply and categorically unrivaLED.

Features

Full Spectrum LED ERS Fixture

Provides high-quality, ERS-style lighting suitable for professional theatre, film, and production environments.

Adjustable Color Temperature

Offers linear color temperature presets from 2800 K to 8000 K with high CRI and CQS for accurate color reproduction.

Virtual Color Wheel

Includes a virtual color wheel with colors precisely matched to popular theatrical gel swatches.

Precise Color Control

Fine-tune your output with plus/minus green adjustment and emulated red-shift, accessible via DMX or on-board controls.

Remote Device Management

RDM capability allows for remote addressing and configuration, adding flexibility to your setup.

Flicker-Free Operation

Adjustable Pulse Width Modulation ensures the light source is flicker-free, making it perfect for on-camera use.

Silent Operation

Engineered for virtually silent operation, this fixture is ideal for noise-sensitive studio, film, and theatre applications.

Ultra-Smooth 18-Bit Dimming

Achieve seamless fades and transitions with ultra-smooth 18-bit dimming curves and adjustable speeds.

Adjustable Yoke

An innovative adjustable yoke allows for easy mounting and positioning, even in areas with low clearance.

Integrated Gobo Rotator Control

Offers direct power, data, and control connections for the Ovation GR-1 gobo rotator accessory.

USB Software Updates

A convenient USB port allows for simple fixture software updates to keep the unit current.

What’s Included

  • Ovation Reve E-3
  • Seetronic Powerkon power cord
  • Ovation Metal Gobo Holder
  • Soft Focus Filter

Additional information

Weight N/A
Optical

Light Source: 91 LEDs (12 red, 19 green, 3 blue, 9 royal blue, 24 amber, 24 mint) 3.5 to 10 W, (2.4 A), 50,000 hours life expectancy (L70)
Color Temperature (range): 2800 to 8000 K
Color Temperature (at full): 5470K
CRI (3200 K): 95.4
Barrel Rotation: +/- 25°
Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
5° Lens:
Beam Angle: 4.6°
Field Angle: 5.6°
Illuminance: 31,856 lux @ 5 m
Lumens: 5,076
10° Lens:
Beam Angle: 10°
Field Angle: 11.1°
Illuminance: 18,924 lux @ 5 m
Lumens: 11,250
14° Lens:
Beam Angle: 14.8°
Field Angle: 16°
Illuminance: 9,284 lux @ 5 m
Lumens: 12,179
15°–30° Lens:
Lumens: 12,057
15°–30° Lens (Narrow):
Beam Angle: 13°
Field Angle: 15.4°
Illuminance: 9,292 lux @ 5 m
15°–30° Lens (Wide):
Beam Angle: 28.5°
Field Angle: 32.2°
Illuminance: 2,671 lux @ 5 m
19° Lens:
Beam Angle: 18.5°
Field Angle: 21.6°
Illuminance: 5,635 lux @ 5 m
Lumens: 12,156
25°–50° Lens:
Lumens: 14,355
25°–50° Lens (Narrow):
Beam Angle: 23.6°
Field Angle: 25.8°
Illuminance: 3,710 lux @ 5 m
25°–50° Lens (Wide):
Beam Angle: 40.5°
Field Angle: 44.1°
Illuminance: 1,527 lux @ 5 m
26° Lens:
Beam Angle: 26°
Field Angle: 29.6°
Illuminance: 3,378 lux @ 5 m
Lumens: 13,300
36° Lens:
Beam Angle: 33.3°
Field Angle: 37.1°
Illuminance: 2,085 lux @ 5 m
Lumens: 13,223
50° Lens:
Beam Angle: 49.5°
Field Angle: 55.7°
Illuminance: 870 lux @ 5 m
Lumens: 12,216
Construction / Physical

Dimensions (fixture only, yoke up): 20.44 x 13.07 x 20.53 in (519 x 332 x 522 mm)
Dimensions (w/5° lens extended, yoke up): 41.60 x 14.17 x 21.42 in (1056 x 360 x 544 mm)
Dimensions (w/10° lens extended, yoke up): 32.87 x 13.07 x 20.01 in (835 x 332 x 510 mm)
Dimensions (w/14° lens extended, yoke up): 29.7 x 13.07 x 20.53 in (755 x 332 x 522 mm)
Dimensions (w/19°, 26°, 36° or 50° lens extended, yoke up):26.83 x 13.07 x 20.53 in (681 X 332 X 522 mm)
Dimensions (w/15°–30° lens, yoke up): 33.02 x 13.52 x 20.53 in (839 x 343 x 522 mm)
Dimensions (w/25°–50° lens, yoke up): 25.74 x 13.52 x 20.53 in (838 x 343 x 522 mm)
Weight (fixture only): 18.6 lb (8.4 kg)
Weight (w/5° lens): 26 lb (11.7 kg)
Weight (w/10° lens): 24 lb (10.8 kg)
Weight (w/14° lens): 25.6 lb (11.6 kg)
Weight (w/26° lens): 24.2 lb (10.9 kg)
Weight (w/15°–30° lens): 32.3 lb (14.6 kg)
Weight (w/25°–50° lens): 29.8 lb ( 13.5 kg)
Exterior Color: Black or White
Gobo Size (Optional): “A”: 100 mm (outside), 75 mm (image), 2.5 mm (max. thickness)
Gobo Size (Optional): “B”: 86 mm (outside), 64.5 mm (image), 2.5 mm (max. thickness)
Accessory Holder/Gel Frame Size (5° lens): 14 in (356 mm)
Accessory Holder/Gel Frame Size (10° lens): 12 in (304 mm)
Accessory Holder/Gel Frame Size (14° lens): 7.5 in (191 mm)
Accessory Holder/Gel Frame Size (19°, 26°, 36°, and 50° lens): 6.25 in (159 mm)
Accessory Holder/Gel Frame Size (15°–30° lens): 7.5 in (191 mm)
Accessory Holder/Gel Frame Size (25°–50° lens): 7.5 in (191 mm)
Connections

Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
Power Input: Seetronic Powerkon IP65
Power Output: Seetronic Powerkon IP65
Data Connectors: 3- and 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
Software Connection: USB
Control

Control Protocol: DMX, RDM
DMX Channels: 1, 5, 6, 8, 12, 14ch1, 14ch2, 18 or HSV
Modes/Personalities: 9 personalities (1, 5, 6, 8, 12, 14ch1, 14ch2, 18, HSV)
Beam Angle

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 4 units @ 120 V; 7 units @ 208 V; 8 units @ 230 V
Power and Current: 367 W, 3.04 A @ 120 V, 60 Hz
Power and Current: 356 W, 1.76 A @ 208 V, 60 Hz
Power and Current: 353 W, 1.59 A @ 230 V, 50 Hz
Certifications / Qualifications

CE, MET, FCC
IP Rating: IP20, dry location
Noise Level (Idle): 17.5 dB(A) @ 1 m
Noise Level (Auto): 24.6 dB(A) @ 1 m
Noise Level (On): 28.7 dB(A) @ 1 m
Noise Level (Off): 12.0 dB(A) @ 1 m
Noise Level (Silent): 19.6 dB(A) @ 1 m
Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
