Chauvet Professional – Ovation H-605FC

Chauvet Professional

The Ovation H-605FC is a convection-cooled, full-color house light that utilizes an RGBA-Lime LED system to deliver a massive color spectrum and a wide range of adjustable white temperatures with advanced control features.

Perfectly suited for theatrical and house of worship applications, its silent operation and superior color rendering provide high-quality illumination without distraction.

Features

  • Offers interchangeable lens plates to easily adapt beam angles for various mounting heights.
  • Achieves exceptionally smooth fades and precise intensity control with 16-bit dimming.
  • Supports advanced control protocols including DMX, WDMX, and RDM for programming flexibility.
  • Features versatile DMX integration with both 5-pin XLR and terminal block connections.
  • Includes a virtual color wheel with presets matched to popular gel colors.
  • Ensures flicker-free performance on camera with adjustable Pulse Width Modulation (PWM).
SKU: OVATIONH605FC Categories: , , ,

Description

Ovation H-605FC takes full advantage of LED technology, utilizing the Ovation standard RGBA-Lime color palette to enable the fixture to replicate nearly any color with tremendous color rendering, as well as nearly any color temperature of white. Superior convection cooling provides excellent output in a compact package. Ideal for theatrical and house of worship applications, setup and control is now easier than ever with the addition of W-DMX, RDM, adjustable PWM and an easy to navigate OLED full text display. White housing not available in European Markets.

Features

Full Color RGBAL LED

A convection-cooled houselight featuring a full-color Red, Green, Blue, Amber, and Lime LED engine for rich, vibrant colors.

Interchangeable Lens Plates

Easily adapt the beam to different mounting heights with swappable lens plates.

Flexible DMX Connections

Offers both 5-pin XLR and terminal block connections for seamless DMX integration.

Versatile Mounting Options

Mount the fixture on a pipe using the included yoke or suspend it via the integrated loop-eye.

Virtual Color Wheel

Access a virtual color wheel with presets matched to popular gel colors for quick and familiar operation.

Adjustable Color Temperature

Select color temperature presets from 2800 K to 6500 K, all with high CRI and CQS for superior light quality.

16-Bit Dimming

Achieve exceptionally smooth fades and precise intensity control with 16-bit dimming.

Advanced Control Protocols

Supports DMX, WDMX, and RDM for enhanced programming flexibility and remote device management.

Flicker-Free Operation

Adjust the Pulse Width Modulation (PWM) to ensure flicker-free performance on camera.

Video

Ovation H-605FC by CHAUVET Professional

Ovation H-605FC takes full advantage of LED technology, utilizing the Ovation standard RGBA-Lime colour palette to enable the fixture to replicate nearly any colour with tremendous colour rendering, as well as nearly any colour temperature of white. Superior convection cooling provides excellent output in a compact package. Ideal for theatrical and house of worship applications, setup and control is now easier than ever with the addition of W-DMX, RDM, adjustable PWM and an easy to navigate OLED full text display.

What’s Included

  • Ovation H-605FC
  • 65°, 45° and 25° lenses
  • 80° filter
  • Egg crate

Additional information

Optical

Light Source: 60 LEDs (12 red, 12 green, 12 blue, 12 amber, 12 lime) 2 to 3 W, (800 mA), 4766 K, 50,000 hours life expectancy
Color Temperature (at full): 5714 K
CRI (5600 K): 87
Beam Angle:
(W/80° Filter): 48°
(W/65° Lens): 68°
(W/45° Lens): 36°
(W/25° Lens): 26°
Field Angle:
(W/80° Filter): 135°
(W/65° Lens): 97°
(W/45° Lens): 82°
(W/25° Lens): 47°
Dimming Modes: 4
Illuminance:
Illuminance (w/80° filter): 147 lux @ 5 m
Illuminance (w/65° lens): 178 lux @ 5 m
Illuminance (w/45° lens): 353 lux @ 5 m
Illuminance (w/25° lens): 652 lux @ 5 m
Lumens (w/80° filter): 4,409
Lumens (w/65° lens): 5,288
Lumens (w/45° lens): 5,446
Lumens (w/25° lens): 5,121
Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6000 Hz, 25,000 Hz
Control

Control Protocol: , DMX, RDM, W-DMX™
DMX Channels: 2, 4, 5, 8, 11, 13, 14, 16 or HSV
Modes/Personalities: 9 personalities (2, 4, 5, 8, 11, 13, 14, 16, HSV)
Certifications / Qualifications

Certifications: CE, MET, FCC
IP Rating: IP20, dry location
Compatible Accessories

W-DMX™ Transmitter
Professional Clamps: CTC-50HC, CTC-50HCN
5-pin DMX Cables
RDM2go
Dynamic Effects

Dimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0 to 27 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Built-in Automated Programs: Yes
Construction / Physical

Dimensions: 13.11 x 9.44 x 13.34 in (333 x 240 x 339 mm)
Weight: 19.6 lb (8.9 kg)
Exterior Color: Black or White
Connections

Power Connection: Bare-wired
Power Input: Hard-wired
Data Connectors: 5-pin XLR, Phoenix connector
Cable Length (power): 15 ft (4.5 m)
Electrical

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 145 W, 1.43 A @ 100 V, 60 Hz
Power and Current: 142 W, 1.19 A @ 120 V, 60 Hz
Power and Current: 146 W, 0.704 A @ 208 V, 60 Hz
Power and Current: 145 W, 0.627 A @ 230 V, 50 Hz
Power and Current: 145 W, 0.605 A @ 240 V, 60 Hz
