| Optical |
Light Source: 91 LEDs (18 red, 18 green, 19 blue, 18 amber, 18 lime green) 3 W, (722 mA), 6031 K, 50,000 hours life expectancy (L70)
Color Temperature (range): 2800 to 6500 K
Color Temperature (at full): 6031 K
CRI (3200 K): 86
Barrel Rotation: +/- 27°
Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
5° Lens:
Beam Angle: 7°
Field Angle: 7°
Illuminance: 16,300 lux @ 5 m
Lumens: 1,807
10° Lens:
Beam Angle: 10°
Field Angle: 10°
Illuminance: 7,430 lux @ 5 m
Lumens: 3,961
14° Lens:
Beam Angle: 11°
Field Angle: 14°
Illuminance: 4,420 lux @ 5 m
Lumens: 2,827
15°–30° Lens (Narrow):
Beam Angle: 13°
Field Angle: 15°
Illuminance: 4,260 lux @ 5 m
Lumens: 4,028
15°–30° Lens (Wide):
Beam Angle: 24°
Field Angle: 29°
Illuminance: 1,620 lux @ 5 m
Lumens: 1,553
19° Lens:
Beam Angle: 19°
Field Angle: 19°
Illuminance: 2,530 lux @ 5 m
Lumens: 3,236
25°–50° Lens (Narrow):
Beam Angle: 23°
Field Angle: 26°
Illuminance: 1,790 lux @ 5 m
Lumens: 5,261
25°–50° Lens (Wide):
Beam Angle: 36°
Field Angle: 50°
Illuminance: 825 lux @ 5 m
Lumens: 7,263
26° Lens:
Beam Angle: 24°
Field Angle: 26°
Illuminance: 1,720 lux @ 5 m
Lumens: 4,316
36° Lens:
Beam Angle: 28°
Field Angle: 34°
Illuminance: 1,020 lux @ 5 m
Lumens: 3,918
50° Lens:
Beam Angle: 41°
Field Angle: 51°
Illuminance: 457 lux @ 5 m
Lumens: 3,813
|
| Control |
Protocol(s): DMX, RDM
DMX Channels: 1, 3, 5, 7, 10, 12, 13, 16 or HSV
Modes/Personalities: 8 personalities (1, 3, 5, 7, 10, 12, 13, 16 or HSV)
|
| Certification / Qualifications |
Certifications: CE, MET, FCC, UKCA
IP Rating: IP20, dry location
Noise Levels:
Idle: 1.0 dB(A) @ 1 m
Auto: 16.8 dB(A) @ 1 m
On: 29.6 dB(A) @ 1 m
Off: 13.8 dB(A) @ 1 m
Silent: 25.6 dB(A) @ 1 m
|
| Required Accessories |
Lens Tube: 19°, 26°, 36°, 50°
|
| Compatible Accessories |
Professional Clamps: CTC-50HC, CTC-50HCN
TRUE1 Style Power Extension cables
3-pin or 5-pin DMX Cables
Color Blending Filters: DF60X1D, DF20D
Ovation Zoom Lenses: OHDZOOM1530, OHDZOOM2550
Gobo Holder: Standard “S4” size Sandwich Style or Iris Slot Style gobo holder for “A” or “B” size gobos
|
| Dynamic Effects |
Dimmer: Electronic
Shutter/Strobe: Electronic
Focus: Manual
Strobe Rate: 0 to 28 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Built-in Automated Programs: Yes
|
| Construction / Physical |
Dimensions:
Fixture Only: 19.49 x 11.22 x 19.17 in (495 x 285 x 487 mm)
w/ 14° Lens Extended: 28.74 x 11.22 x 19.17 in (730 x 285 x 487 mm)
w/ 26° Lens Extended: 25.91 x 11.22 x 19.17 in (658 x 285 x 487 mm)
w/ 15°–30° Lens: 32.87 x 14.61 x 14.61 in (835 x 371 x 371 mm)
w/ 25°–50° Lens: 27.17 x 14.61 x 14.61 in (690 x 371 x 371 mm)
Weight:
Fixture Only: 15.4 lb (7.1 kg)
w/ 14° Lens: 20.8 lb (9.43 kg)
w/ 26° Lens: 19.8 lb (9 kg)
w/ 15°–30° Lens: 29.4 lb (13.3 kg)
w/ 25°–50° Lens: 27 lb (12.2 kg)
Exterior Color: Black or White
Gobo Size (Optional):
“A”: 100 mm (outside), 75 mm (image), 2.5 mm (max. thickness)
“B”: 86 mm (outside), 64.5 mm (image), 2.5 mm (max. thickness)
Accessory Holder/Gel Frame Size:
5° Lens: 14 in (356 mm)
10° Lens: 12 in (304 mm)
14° Lens: 7.5 in (191 mm)
19°, 26°, 36°, and 50° Lens: 6.25 in (159 mm)
15°–30° Lens: 7.5 in (191 mm)
25°–50° Lens: 7.5 in (191 mm)
|
| Connections |
Protocol(s): DMX, RDM
DMX Channels: 1, 3, 5, 7, 10, 12, 13, 16 or HSV
Modes/Personalities: 8 personalities (1, 3, 5, 7, 10, 12, 13, 16 or HSV)
|
| Electrical |
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 5 units @ 100 V; 6 units @ 120 V; 11 units @ 208 V; 12 units @ 230 V; 13 units @ 240 V
Power and Current: 220 W, 2.17 A @ 100 V, 60 Hz
Power and Current: 215 W, 1.79 A @ 120 V, 60 Hz
Power and Current: 214 W, 1.03 A @ 208 V, 60 Hz
Power and Current: 216 W, .94 A @ 230 V, 50 Hz
Power and Current: 217 W, .91 A @ 240 V, 50 Hz
|
