| Optical |
Light Source: 1 LED (WW) 230 W, (3.6 A), 3149 K, 50,000 hours life expectancy; (CW) 230 W, (3.5 A), 5452 K, 50,000 hours life expectancy
Color Temperature (at full): (WW) 3149 K; (CW) 5452 K
CRI: (WW) 96; (CW) 96
Beam Angle:
(W/5° Lens): 6°
(W/10° Lens): 8°
(W/14° Lens): 11°
(W/19° Lens): 13°
(W/26° Lens): 16°
(W/36° Lens): 20°
(W/50° Lens): 28°
(w/15°–30° lens)(Narrow): 12°
(w/15°–30° lens)(Wide): 14°
(w/25°–50° lens)(Narrow): 21°
(w/25°–50° lens)(Wide): 22°
Field Angle:
(W/5° Lens): 7°
(W/10° Lens): 10°
(W/14° Lens): 14°
(W/19° Lens): 18°
(W/26° Lens): 25°
(W/36° Lens): 34°
(W/50° Lens): 50°
(w/15°–30° lens)(Narrow): 15°
(w/15°–30° lens)(Wide): 29°
(w/25°–50° lens)(Narrow): 26°
(w/25°–50° lens)(Wide): 46°
Dimming Modes: 4
Lumens (w/19° lens): (WW) 7,587; (CW) 9,530
Lumens (w/26° lens): (WW) 10,284; (CW) 13,368
Lumens (w/36° lens): (WW) 10,121; (CW) 13,184
Lumens (w/50° lens): (WW) 9,655; (CW) 12,672
Illuminance:
Illuminance (w/5° lens): (WW) 41,400 lux @ 5 m; (CW) 49,200 lux @ 5 m
Illuminance (w/10° lens): (WW) 23,300 lux @ 5 m; (CW) 26,600 lux @ 5 m
Illuminance (w/14° lens): (WW) 13,439 lux @ 5 m; (CW) 16,787 lux @ 5 m
Illuminance (w/19° lens): (WW) 9,256 lux @ 5 m; (CW) 10,674 lux @ 5 m
Illuminance (w/26° lens): (WW) 6,910 lux @ 5 m; (CW) 8652 lux @ 5 m
Illuminance (w/36° lens): (WW)4,053 lux @ 5 m; (CW) 5185 lux @ 5 m
Illuminance (w/50° lens): (WW)1,703 lux @ 5 m; (CW) 2181 lux @ 5 m
Illuminance (w/15°–30° lens)(Narrow): (WW) 16,827 lux @ 5 m ; (CW) 19,900 lux @ 5 m
Illuminance (w/15°–30° lens)(Wide): (WW) 10,626 lux @ 5 m; (CW) 10,159 lux @ 5 m
Illuminance (w/25°–50° lens)(Narrow): (WW) 7,210 lux @ 5 m; (CW) 9,219 lux @ 5 m
Illuminance (w/25°–50° lens)(Wide): (WW) 3,295 lux @ 5 m; (CW) 3,468 lux @ 5 m
Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
|
| Construction / Physical |
Dimensions:
Dimensions (fixture only): 19.49 x 11.22 x 19.17 in (495 x 285 x 487 mm)
Dimensions (w/5° lens extended): 42.79 x 14.17 x 14.48 in (1087 x 360 x 368 mm)
Dimensions (w/10° lens extended): 34.09 x 12.16 x 12.48 in (866 x 309 x 317 mm)
Dimensions (w/14° lens extended): 28.74 x 11.22 x 19.17 in (730 x 285 x 487 mm)
Dimensions (w/26° lens extended): 25.91 x 11.22 x 19.17 in (658 x 285 x 487 mm)
Dimensions (w/15°–30° lens): 32.87 x 14.61 x 14.61 in (835 x 371 x 371 mm)
Dimensions (w/25°–50° lens): 27.17 x 14.61 x 14.61 in (690 x 371 x 371 mm)
Weights:
Weight (fixture only): 15.4 lb (7 kg)
Weight (w/5° lens): 21.2 lb (9.7 kg)
Weight (w/10° lens): 19.2 lb (8.8 kg)
Weight (w/14° lens): 20.8 lb (9.43 kg)
Weight (w/26° lens): 19.4 lb (8.80 kg)
Weight (w/15°–30° lens): 29.4 lb (13.34 kg)
Weight (w/25°–50° lens): 27 lb (12.25 kg)
Exterior Color: Black or White
Gobo Size (Optional): “A”: 100 mm (outside), 75 mm (image), 2.5 mm (max. thickness)
Gobo Size (Optional): “B”: 86 mm (outside), 64.5 mm (image), 2.5 mm (max. thickness)
Accessory Holder/Gel Frame Size:
(5° Lens): 14 in (356 mm)
(10° Lens): 12 in (304 mm)
(14° Lens): 7.5 in (191 mm)
(19°, 26°, 36°, And 50° Lens): 6.25 in (159 mm)
(15°–30° Lens): 7.5 in (191 mm)
(25°–50° Lens): 7.5 in (191 mm)
|
| Electrical |
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 6 units @ 120 V; 10 units @ 208 V; 12 units @ 230 V;
Power and current: (WW) 225 W, 2.36 A @ 100 V. 60 Hz
(CW) 225 W, 2.23 A @ 100 V, 60 Hz
Power and Current: 223 W, 1.84 A @ 120 V, 60 Hz
Power and Current: 230 W, 1.10 A @ 208 V, 60 Hz
Power and Current: 231 W, 1.00 A @ 230 V, 50 Hz
Power and Current: (WW) 232 W, 1.02 A @ 240 V, 60 HZ
(CW) 232 W, 0.96 A @ 240 V, 60 Hz
|
