Chauvet Professional - Ovation E-2 FC Front Right of fixtureChauvet Professional - Ovation E-2 FC Front Right of fixture

Chauvet Professional – Ovation E-2 FC

Chauvet Professional

A compact LED ellipsoidal spotlight delivering high-CRI, full-spectrum RGBA-Lime color mixing with an integrated manual zoom and a dedicated focus mode.

Its quiet and durable design is optimized for smaller venues requiring high-quality light and silent operation.

Features

  • Delivers an adjustable color temperature from 2800 K to 8000 K with a high CRI of 93.
  • Provides a versatile 25° to 50° manual zoom range for precise beam shaping and coverage.
  • Offers advanced color control with plus/minus green adjustment and emulated red-shift.
  • Achieves exceptionally smooth fades and transitions with advanced 18-bit dimming curves.
  • Supports DMX and RDM protocols with nine personalities for flexible control integration.
  • Simplifies installations with power linking for up to 7 units at 120 V.
SKU: CHAOVATIONE2FC Categories: , , ,

Description

Ovation E-2 FC is a compact LED ellipsoidal spotlight that delivers high quality of light and convenient features in a quiet durable design optimized for smaller venues. Its advanced full spectrum Ovation color mixing system produces exceptionally high CRI output that can be smoothly sized with an integrated manual Zoom and focusing made easier with a dedicated Focus Mode button.

Features

Full Spectrum LED Fixture

An ERS-style LED light designed for vibrant, full-spectrum color in small theaters and studios.

Integrated Zoom Lens

Features a built-in 25 to 50 degree zoom lens for flexible beam angle adjustments.

Adjustable Color Temperature

Offers a wide range of color temperature presets from 2800 K to 8000 K with high color rendering.

Advanced Color Control

Provides precise plus/minus green adjustment and emulated red-shift effects via DMX or on-board controls.

One-Touch Focus Mode

A dedicated button allows for instant activation of a focus mode, simplifying adjustments without a console operator.

Smooth 18-Bit Dimming

Delivers exceptionally smooth dimming curves and speeds to seamlessly complement any lighting scheme.

USB Software Updates

Includes a convenient USB port for easy and straightforward fixture software updates.

Video

Meet Ovation E-2 FC from CHAUVET Professional!

A new prodigy that arrives in a brilliantly conceived compact form! Ovation E-2 FC is a compact LED ellipsoidal spotlight that delivers high quality of light and convenient features in a quiet durable design.

What’s Included

  • Ovation E-2FC
  • Seetronic Powerkon power cord
  • Ovation Metal Gobo Holder (“M” Size)
  • Soft Focus Filter
  • Quick Reference Guide or User Manual

Additional information

Optical

Light Source: 72 LEDs (15 reds 11 green, 6 blue, 4 cyan, 14 amber, 22 lime) 6 to 9.75 W, (1.5 A) 50,000 hours life expectancy
Color Temperature (range): 2800 to 8000 K
Color Temperature (at full): 4525 K
CRI (3200 K): 93
Beam Angle:
Spot: 23.8°
Flood: 46.4°
50% Zoom: 38.7°
Field Angle:
Spot: 25.6°
Flood: 51°
50% Zoom: 41.3°
Cutoff Angle:
Spot: 24.9°
Flood: 51.8°
50% Zoom: 41.9°
Zoom Range: 23.8° to 51.8°
Lumens (Spot): 3708 lm
Lumens (Flood): 5608 lm
Lumens (50% Zoom): 5147 lm
Illuminance:
Illuminance (Spot): 1107 lux @ 5 m
Illuminance (Flood): 488 lux @ 5 m
Illuminance (50% Zoom): 595 lux @ 5 m
Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
Connections

Power Connection: Edison (Local) plug to Seetronic Powercon IP65
Power Input: Seetronic Powercon IP65
Power Output: Seetronic Powercon IP65
Data Connectors: 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
Software Connection: USB
Certification / Qualifications

Certifications: CE, MET, FCC, UKCA
IP Rating: IP20, dry location
Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
Compatible Accessories

Professional Clamps: CTC-50HC, CTC-50HCN
Seetronic Powerkon power linking cables
5-pin DMX Cables
Ovation E-2 Iris (Model: OVE2IRIS)
Dynamic Effects

Framing Shutters: Yes
Dimmer: Electronic
Shutter/Strobe: Electronic
Zoom: Manual
Focus: Manual
Strobe Rate: 0 to 25 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Dim Curves: 4
Built-in Automated Programs: Yes
Construction / Physical

Dimensions: 18.1 x 12.2 x 17.5 in (461 x 310 x 445 mm)
Weight: 14.8 lb (6.7 kg)
Exterior Color: Black
Housing Material: Aluminum die-cast
Accessory Holder/Gel Frame Size: 6.25 in (159 mm)
Gobo Size (Optional): “M”: 66 mm (outside), 48 mm (image), 2 mm (max. thickness)
Control

Control Protocol: DMX, RDM
DMX Channels: 1, 4, 5, 7, 11, 13ch1, 13ch2, 17 or HSV
Modes/Personalities: 9 personalities (1, 4, 5, 7, 11, 13ch1, 13ch2, 17 or HSV)
Electrical

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 7 units @ 120 V; 10 units @ 208 V; 12 units @ 230 V
Power and Current: 208 W, 1.71 A @ 120 V, 60 Hz
Power and Current: 219 W, 1.10 A @ 208 V, 60 Hz
Power and Current: 220 W, 0.98 A @ 230 V, 50 Hz
