Description
With superb dimming performance, an expansive 18:1 zoom, and a full armory of features, Maverick Force X Profile is a compact LED moving profile ready for a wide range of short and long throw applications. This fast lightweight powerhouse combines the latest Maverick series technical advancements to achieve 18,963 lumens of output in a design that maintains a flat field of focus all the way from its narrow 3.5° beam to a broad 57.3° spot. Color calibration and gobo selection comes matched to other Force fixtures in the rig, along with an advanced 4-blade shutter frame system and a wheelhouse that includes a variable CMY color mixing system renowned for its real reds, color wheel with CRI and CTB filters, static and rotating gobo wheels, five-facet prism, iris, and frost. Take control with DMX, RDM, sACN, Art-Net, or CRMX.
Compact LED Profile Fixture
A fully featured, compact, and lightweight 520W LED yoke profile fixture.
Variable CMY Color Mixing
Create a wide pallet of colors using the integrated CMY color mixing system and a separate color wheel.
Dual Gobo Wheels
Expand creative options with two gobo wheels, one featuring rotating gobos and one with static gobos.
Smooth 16-Bit Dimming
Achieve exceptionally smooth control of fades with 16-bit dimming of the master dimmer.
High-Speed PWM
A 65,000 PWM ensures flicker-free operation for use with the fastest frame cameras while maintaining fantastic dimming.
Flexible Control Options
Offers full flexibility of control with support for DMX, WDMX, sACN, and Art-Net.
RDM Enabled
Allows for remote addressing and troubleshooting for simplified fixture management.
Wide Zoom Range
Accommodate variable beam sizes with an expansive 3.5° to 57.3° zoom range.
Advanced Beam Control
Shape and modify the beam using the built-in iris, 5-facet prism, and frost effects.
Rotatable Framing System
Utilize a 4-blade framing shutter system with dual-axis movement, full wipe, and 120-degree module rotation.
Professional Power Input
Features a secure, True-1 compatible power input for reliable connections.
Easy Shop Setup
Three setup menu presets and a preset sync function allow for easy cross-loading to multiple fixtures.
USB Software Updates
Keep the fixture’s software current using the convenient onboard USB slot for uploads.
Battery Backup Display
Access the menu without main power thanks to the battery-backed display that auto-rotates depending on fixture orientation.
Failsafe Ethernet Connectivity
Allows data to pass through to the next fixture even if the unit’s power is lost.
NFC Configuration
Quickly and easily set up the fixture in the shop or field using Near Field Communication.
Video
Light Snacks: Maverick Force X Spot & X Profile Overview
In this episode of Light Snacks, Sr. Product Manager Michael Graham spotlights the Maverick Force X Spot and Maverick Force X Profile, two compact fixtures designed to deliver smooth color, sharp optics, and versatile effects.
