Chauvet Professional – COLORdash Batten H12X IP

Chauvet Professional

A rugged, IP65-rated linear wash batten featuring twelve individually-controllable hex-color RGBWAUV LEDs that deliver a high-output, broad color palette with pixel-mapping capabilities.

Perfect for any indoor or outdoor production, broadcast, or live event that requires a durable, all-weather linear fixture for powerful washes and dynamic eye-candy effects.

Features

  • Delivers over 4,700 lumens of output from twelve 10W hex-color (RGBWA+UV) LEDs.
  • Provides a wide 24.9° beam angle and 40.7° field angle for broad, even wash coverage.
  • Features four selectable dimming curves and adjustable PWM for smooth, flicker-free on-camera performance.
  • Maintains an even pixel pitch between fixtures to create seamless, dynamic pixel-mapped effects.
  • Supports both DMX and RDM protocols with eight personalities for versatile control integration.
  • Offers flexible mounting with hanging brackets that double as floor stands for versatile placement.
SKU: COLORDASHBATTENH12XIP Categories: , , ,

Description

The rugged COLORdash Batten H12X IP RGBWAUV linear LED wash efficiently delivers a broad palette of subtle to saturated color with beautiful precision, weighing in under 18 lbs while delivering over 4,700 lumens of output. Flawlessly smooth 16-bit fades with four selectable dimming curves. Flicker-free output with multiple PWM frequencies. Maintains an even pixel pitch for perfect pixel mapped looks when used in multiples. Setup is easy with hanging brackets that double as floor stands. With RDM to remotely choose its DMX personality and an OLED display to easily read its onboard menu, COLORdash Batten H12X IP offers convenient operation and excellent performance as an IP65-rated all-weather die-cast workhorse at home in any environment, in the rig or on the floor, live or on camera, indoor or out.

Features

Versatile LED Batten

This rugged RGBWA-UV LED batten is designed for events requiring indoor and outdoor flexibility.

IP Rated Weatherproofing

Operates reliably in any weather conditions thanks to its IP rated power and DMX connections.

Flicker-Free Operation

Adjustable Pulse Width Modulation (PWM) ensures the light output is free of flickering when on camera.

Remote Device Management

RDM capability adds flexibility by allowing you to address and configure the fixture remotely.

Smooth Dimming Curves

Selectable, smooth dimming curves eliminate flicker and choppiness for seamless fades.

Intuitive OLED Display

An easy-to-read, password-protected OLED touchscreen interface allows for simple onboard control.

Advanced Optics

The advanced optical system provides exceptional color mixing and high-efficiency light output.

Flexible Mounting Options

Included floor trunions and an omega bracket allow for easy hanging and versatile placement.

What’s Included

  • Colordash Batten H12X IP
  • Neutrik powerCON TRUE1 power cord
  • Omega Bracket (2pc)

Additional information

Optical

Light Source: 12 LEDs (RGBAW+UV) 10 W, (532 mA), 50,000 hours life expectancy
Color Temperature (at full): 11567 K
Beam Angle: 24.9°
Field Angle: 40.7°
Lumens: 4,796 lm
Illuminance (total): 881 lux @ 5 m
Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz
Connections

Power Connection: Edison (local) plug to Seetronic Powerkon IP65
Power Input: Seetronic Powerkon IP65
Power Output: Seetronic Powerkon IP65
Data Connectors: 3- and 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
Electrical

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 9 units @ 120 V; 16 units @ 208 V; 17 units @ 230 V
Power and Current: 154 W, 1.284 A @ 120 V, 60 Hz
Power and Current: 151 W, 0.741 A @ 208 V, 60 Hz
Power and Current: 151 W, 0.667 A @ 230 V, 50 Hz
Compatible Accessories

Professional Clamps: CTC-50HC, CTC-50HCN
Seetronic Powercon power linking cables
5-pin IP DMX Cables
Dynamic Effects

Dimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0 to 23 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes/No
Dim Modes: 4
Built-in Automated Programs: Yes
Construction / Physical

Dimensions: 39.4 x 8.129 x 3.78 in (1000 x 208 x 96 mm)
Weight: 17.4 lb (8 kg)
Exterior Color: Black
Housing Material: Aluminum diecast
Control

Control Protocol: DMX, RDM
DMX Channels: 6, 8, 9, 13, 14, 42, 47 or 59
Modes/Personalities: 8 personalities (6, 8, 9, 13, 14, 42, 47, 59)
Certifications / Qualifications

Certifications: CE, MET, UKCA, FCC
IP Rating: IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
IP Rating: IP66, outdoor/wet, with pressure equalizing M12 GORE valve
Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
