Chauvet-Professional-COLORado-Solo-Edge-1-Front-RightChauvet-Professional-COLORado-Solo-Edge-1-Front-Right

Chauvet Professional – COLORado Solo Edge 1

Chauvet Professional

A low-profile, 0.5-meter IP65 footlight with a single-source lens for smooth, even output and fully controllable RGB marker lights for stage-edge visibility.

Designed for seamless end-to-end alignment, it delivers elegant, unobtrusive stage lighting for theatre, touring, and broadcast applications where clean aesthetics are paramount.

Features

  • Low-profile, 0.5mIP65 rated footlight with full-color and high-quality white light
  • Single-source lens for smooth, even output with no distracting points of light and an additional “stealth” filter to help the fixture disappear when off
  • Additional, fully controllable RGB marker lights can be used to cue talent or mark the edge of a stage
  • Designed for end-to-end use with no gaps or distracting cable mess, and a covered display to keep everything elegant unseen.
SKU: COLORADOSOLOEDGE1 Categories: , , ,

Description

This low-profile 0.5-meter IP65-rated RGBwWL LED footlight projects high-quality white light and a full range of color through a single-source lens designed to produce smooth, even output. Featuring fully-controllable RGB marker lights that can be used to cue talent or mark the edge of a stage, seamless end-to-end alignment, and a covered display, this elegant fixture also comes with a stealth filter that enables it to disappear when off.

Features

Rugged, Low-Profile Design

Its IP65-rated, low-profile housing delivers high-quality white and full-color light for demanding indoor or temporary outdoor stage environments.

Smooth, Unobtrusive Output

A single-source lens produces smooth, even washes, while the included stealth filter helps the fixture visually disappear when not in use.

Integrated Marker Lights

Use the fully controllable RGB marker lights to provide visual cues for performers or clearly define the edge of any stage.

Seamless End-to-End Alignment

Create clean, uninterrupted lines of light with end-to-end connections and a covered display that conceals distracting cables and settings.

What’s Included

  • COLORado Solo Edge 1
  • Seetronic Powerkon IP65
  • Power and Data linking cables
  • Stealth Filter
  • 2 Omega bracket with mounting hardware

Additional information

Optical

Light Source:
Primary: 56 LEDs (Quintuple-color RGBWL)
RGB Markers: 6 LEDs (Tri-color RGB)
Color Temperature (range): 2800 to 8000 K
Color Temperature (at full): 6516 K
CRI @ 3200K: 93.1
Beam Angle:
Horizontal: 118.2°
Vertical: 120.1°
Horizontal (Stealth Filter): 88.4°
Vertical (Stealth Filter): 89.2°
Field Angle:
Horizontal: 154.4°
Vertical: 155.2°
Horizontal (Stealth Filter): 139.1°
Vertical (Stealth Filter): 128.8°
Lumens:
Without Stealth Filter: 6,988
With Stealth Filter: 1,731
Illuminance:
Without Stealth Filter: 107 lux @ 5 m
With Stealth Filter: 37 lux @ 5 m
Control

Control Protocol: Art-Net, sACN, DMX, RDM
DMX Channels:
1 Cell: 5, 6, 6, 6, 6, 7, 11, 12, 12, 13, 14 or 21
2 Cell: 8, 9, 9, 10, 12, 19, 21, 22, 23 or 37
Art-Net Channels:
1 Cell: 5, 6, 6, 6, 6, 7, 11, 12, 12, 13, 14 or 21
2 Cell: 8, 9, 9, 10, 12, 19, 21, 22, 23 or 37
Modes/Personalities: Personalities (22)
Certifications / Qualifications

Compliance: CE, MET, ROHS
MET Listing Number: [E113093-1110, E113093-1125]
US Safety: [UL 60950-1]
Canadian Safety: [CSA C22.2 No. 60950-1]
Temperature (Ambient): -4 °F to 122 °F (-20 °C to 50° C)
Dynamic Effects

Dimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0 to 30Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Dim Curves: 4
Built-in Automated Programs: Yes
Customizable Programs: Yes
Construction / Physical

Dimensions: 19.68 x 8.85 x 2.51 in (500 x 225 x 64 mm)
Weight: 12.52 lb (5.68 kg)
Exterior Color: Black
Housing Material: Aluminum alloy and Aluminum die-cast
IP Rating: IP66
Connections

Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
Power Input: Seetronic Powerkon IP65
Power Output: Seetronic Powerkon IP65
Data Connectors: 5-pin IP65 XLR, Seetronic etherCON
Cable Length (power): 5 ft (1.5 m)
Software Connection: USB, Ethernet (RJ45)
Electrical

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 11 units @ 120 V; 19 units @ 208 V; 21 units @ 230 V;
Power and Current: 126 W, 1.05 A @ 120 V, 60 Hz
Power and Current: 125 W, 0.61 A @ 208 V, 60 Hz
Power and Current: 125 W, 0.55 A @ 230 V, 50 Hz
Battery

Battery Type: Lithium Ion
Rechargeable: Yes
Battery Power
Li-ion Battery: 3.7Vdc, 200mAh
Li-Button: 3Vdc, 1000mAh
Required Accessories

Required Software: Chamsys, QuickQ, DMX Workshop, etc.
Controller (required): [Drivers, processors, etc.]
Compatible Mounting Options: [140DX OMEGA BRACKET, M12 BOLT, VELCRO, ETC.]
