Chamsys – GeNetix GS5IP

Chamsys

GeNetix Switch 5IP is a five-port IP65-rated unmanaged Gigabit network switch that can be powered either via PoE or via Mains power to its PowerCon True1 Mains Input connector.

Features

  • 5 port Unmanaged Gigabit Network Switch
  • IP65 Rated
  • Locking Ethernet Connectors
  • Can be mains or PoE Powered
  • PowerCon True1 Top Mains Input
  • M12 Threaded Insert for Clamp Mounting
  • Built in Rail for secondary Safety bond when rigged

Description

GeNetix Switch 5IP is a five-port IP65-rated unmanaged Gigabit network switch that can be powered either via PoE or via Mains power to its PowerCon True1 Mains Input connector. This compact and rugged all-weather device comes with multiple rigging options for easily mounting in your rig. Port Status LEDs provide visual indication to know if ports are connected/active and if running at Gigabit speed.

Video

Introducing GeNetix: Our Growing Family of Intuitive Networking Devices by ChamSys

Introducing GeNetix! On the wall or in the rig, GeNetix simplifies data distribution with a complete range of Nodes, Gateways, Switches and PoE devices.

Additional information

Hardware Specifications

Network Ports: 5
Mains Input: PowerCon True1 Top
Can be PoE Powered: Yes
Port Status LEDs: Yes
M12 Clamp Fixing: Yes
Safety Bond Fixing Rail: Yes
Max Power Consumption (mains): 30w

Included Accessories

Neutrik powerCON TRUE1 Power Cable: 1

Software Specifications

Gigabit Ethernet: Yes
Unmanaged Network Switch: Yes

Node Weights and Dimensions

Width: 274mm (10.81 inches)
Depth: 76mm (3,0 inches)
Height: 68mm (2.68 inches)
Weight: 1.40 KG (3.09 lb)

Downloads

Data Sheet Download
