Cameo – AZOR® W2

Cameo

The AZOR® W2 is a compact 7x40W RGBL wash moving head with wide zoom, pixel control, and a hidden Eclipse Burst Effect for stunning strobe visuals.

SKU: CAMCLAZORW2 Categories: , , ,

Description

Every year, countless artists, bands, actors and presenters stand on small to medium-sized stages and need light! For all these events, Cameo has developed the AZOR® W2. The compact wash moving head is the ideal partner for lighting designers and event service providers who are looking for a powerful and versatile LED show light that does not lack professional features despite its compact size.

Offering 7 x 40W RGBL LEDs with a total output of 3,600 lm and a zoom range of 4° – 50°, the AZOR® W2 holds a secret. The real magic lies in its discreet feature – the Eclipse Burst Effect. Behind a dark filter, this innovative addition introduces 4 segment SMD-LEDs, creating captivating strobe and pixel effects. Paired with single-pixel control, the AZOR® W2 promises an audience experience that goes beyond the ordinary.

Thanks to the adjustable PWM frequency, the AZOR® W2 is also suitable for use in TV and broadcast applications as well as wherever a camera transmits the action and is dependent on flicker-free LEDs in the picture.

The compact wash moving head can be controlled via DMX512, RDM or wirelessly via W-DMX using the optional Cameo iDMX stick. On the wash light itself, buttons and an OLED display provide a convenient basic setup.

Features

  • 7 x 40 W RGBL LED with 3,600 lm luminous flux
  • Zoom range: 4° – 50°
  • Single pixel control of all 7 LEDs
  • Eclipse Burst Effect* for strobe and pixel effects
  • Selectable PWM frequencies
  • iDMX stick input for wireless DMX connection
  • OLED display with 4 buttons

Video

CAMEO AZOR® Series – COMPACT DESIGN. DO EPIC.

Create something epic with the compact moving heads from the AZOR® series! Fans of versatility will find what they are looking for here, because this product range has it all.

Additional information

Photometric values

Illuminant type: LED RGBL
Illuminant power: 40 W
Luminous flux: 3,600 lm
Exchangable lens: No
Exchangable optics: No
Beam/Field angle: 4° / 50°
Zoom range: 4 – 50 °
LED PWM frequency: 650 Hz, 1,530 Hz, 3,600 Hz
Dimmer resolution: 16 Bit
Dimmer curves: Linear, Exponential, Logarithmic, S curve
Power mode: Standard

Colours

Colour mix functions: RGB
LED colours: Red, Green, Blue, Lime, Cold white
Correlated colour temperature (CCT): 2,200 – 6,800 K
Halogen simulation redshift/DTW: No
Calibration: Factory calibration, RAW

Movement

Pan: 630 °
Tilt: 250 °

Effects

Iris: No
Animation: No
Framing blades: No

Control

Controller protocols: DMX512, RDM
Number of DMX control modes: 9
Data in connector: XLR 5-pole male

Mains operation

Rated power: 503 W
Min. Cos Phi power factor (230 V): 0.94
Rated current: 2.2 A
Mains connector: Mains plug device male IP65
Power out: Mains plug device female IP65
Mains fuse: T4AL/250 V

Housing

Chassis material: Plastic
Colour: Black

Cooling

Cooling system: Fan cooling

Environmental

Protection class: IP20
Noise level in operation: 40 dB
Maximum air humidity (non-condensing): 85 %

Dimensions & weight

Width: 308 mm
Height: 414 mm
Depth: 193 mm
Weight: 8.6 kg

Other properties

Included Accessories: Omega adaptor, Mains cable

Downloads

Data Sheet Download
User Guide Download
