Description
Compact designed from small to medium stages. The AZOR® SP2 is made for artists, bands and actors on stages and theaters. The benefits of a classic spot with the addition of motorized framing blades on 4 layers, rotatable by +/- 60°. An ideal partner for lighting designers and event service providers who are looking for a powerful and versatile LED show light – all of that in a compact housing.
The AZOR® SP2 is based on a 300 W LED light source with 13,000 lumens of luminous flux and a wide zoom range of 3°-50° for precise adjustment of the light beam on any stage. The integrated rotating CMY colour mixing system is complemented by an additional colour wheel with 8 dichroic filters to perform lightning-fast colour changes and split colours in conjunction with the 630° pan and 270° tilt movement.
Providing a spectrum of dynamic patterns and precise color temperature control for lighting designers, the compact spot profile moving head features a gobo wheel with 7 rotating gobos and a linear CTO to create remarkable visual effects and achieve a unique atmosphere.
Thanks to the adjustable PWM frequency (650 Hz – 25 kHz), the AZOR® SP2 is also suitable for use in TV and broadcast applications as well as wherever a camera transmits the action and is dependent on flicker-free LEDs in the picture. It can be controlled via DMX512, RDM or wirelessly via W-DMX using the optional Cameo iDMX adapter. On the fixture itself, buttons and an OLED display provide a convenient basic setup.
Features
- 300 W LED with 13,000 lm luminous flux
- Motorized framing blades on 4 layers (+/- 60° roatable)
- Zoom range: 3° – 50°
- CMY colour mixing and additional colour wheel with 8 dichroic colour filters
- Rotating gobo wheel with 7 indexable/rotatable, exchangeable glass gobos + open
- Overlapping prisms (circular)
- Linear CTO for colour temperature modulation in lighting setups
- Selectable PWM frequencies up to 25 kHz for flicker-free operation
- Silent operation in 3 noise-modes
Video
CAMEO AZOR® Series – COMPACT DESIGN. DO EPIC.
Create something epic with the compact moving heads from the AZOR® series! Fans of versatility will find what they are looking for here, because this product range has it all.
