Embed up to 2 channels of audio from balanced analog, optical or HiFi RCA, or embed up to or 4 channels of AES/EBU digital audio into any SD, HD, Ultra HD or DCI 4K SDI video connection. Take audio from devices such as audio mixers, iPods and analog decks and embed it into SDI video connections for use with SDI routers and decks.
| SDI Video Inputs | 1 x 12G-SDI SD/HD/2K/4K auto switching. |
|---|---|
| SDI Video Outputs | 1 x 12G-SDI output. |
| Analog Audio Inputs | 2 channels professional balanced analog audio via XLR connectors, or 2 channel unbalanced analog line level via RCA connectors. Right XLR can be configured for timecode input. |
| Digital Audio Inputs | 4 channels professional 110Ω balanced digital audio via XLR connectors. Right XLR can be configured for timecode input. |
| Embedded Audio Support | 16 channels. |
| Optical Audio Input | S/PDIF Signal with TOSLINK Connector. |
| Multi Rate Support | Automatic switching between SD/HD/2K and 4K. |
| Updates and Configuration | USB or Ethernet. |
| Reclocking | Yes |
