Ayrton - WildSun K9 Wash Front Left of moving headAyrton - WildSun K9 Wash Front Left of moving head

Ayrton – WildSun K9 Wash

Ayrton

The new WildSun K9 Wash is a highly evolved variant of the WildSun K25 TC, specially geared to shooting TV video and broadcasting in high-definition.

SKU: 013940 Categories: , , ,

Description

With a brand new sleek design and a visual footprint 20% smaller, its weight has been drastically reduced by 25%, allowing for better integration. This unique LED luminaire measures up to the classic Fresnel HMI 4000 lights in terms of pure output. Fitted with 217 next-generation high-output LEDs, the luminaire delivers more than 60,000 lumens of overall output with 40% less energy consumption. No lamp replacement is necessary. Producing extremely high-quality light without flickering, this luminaire achieves a colour temperature perfectly calibrated at 5700K and a colour rendering index greater than 92. WildSun K9 Wash is particularly suitable for sporting events, fashion shows, car shows, or any prestigious events requiring powerful, high-quality light and perfectly rendered colour.

WildSun K9 Wash is a powerhouse of technology and innovation. With the same basic specifications as WildSun K25 TC, it is equipped with powerful tri-phase stepper motors that allow fast, accurate and silent positioning.

Ayrton developed special silicone-based high-output optics for this projector, ensuring perfect stability over time. Its optical zoom has a 6:1 ratio with a zoom range of 10° to 60°. Luminous intensity can be fine-tuned using a precision electronic dimmer, for even greater flexibility of use. The light fixture output is equipped with a protective holographic filter in polycarbonate and an honeycomb system to prevent glare. The user can control each concentric circle individually to adjust the luminaire’s power accordingly or create dynamic effects for stage lighting.

Features

  • Luminous Flux63,000 lm
  • Native CRI> 92
  • Zoom Aperture10° to 60°
  • Front Lens384 mm
  • IP RatingIP20
  • Weight26.9 kg

Video

Additional information

Weight 26.9 kg
Optics

1 element 6:1 zoom high-resolution optic system
Beam aperture: 10 ° to 60 °
Fast motorised linear zoom
217 individual lenses
384 mm front lens cluster

Light Source

217 mono-chip High-Power LED sources
Total luminaire output: up to 63,000 lumen
CRI: greater than 92
Rated life (L70): up to 40,000 hours
Flicker free sources management, suitable for TV applications and all video recorded events

Movement

Extremely accurate positioning
Moving-head operated via either 8 or 16 bit resolution
High-resolution stepper motors operated via microprocessors ensure extreme accuracy and smooth movements.
PAN and TILT automatic repositioning
Moving-head range: 540 ° (pan), 270 ° (tilt)

Colours

Monochromatic daylight source perfectly calibrated at 5700 K

Dimmer / Strobe

Electronic dimmer, allowing perfect light adjustment from 0 to 100%
Strobe effect, with speed adjustment from 1 to 25 flashes per second

Software Features

Local DMX addressing of luminaire and optional parameters through its built-in LCD control panel
Remote DMX addressing of luminaire and optional parameters through a standard RDM DMX controller
Information menu including hour counter, temperature, software version

Hardware Features

Graphic LCD display for addressing and special functions settings, with flip function
Clicking jog wheel to set functions
Excess temperature protection
Integrated wireless CRMX TiMo™ RDM receiver from LumenRadio™
XLR 5 pin male and female connectors for DMX connection
etherCON RJ45 IN / OUT connectors for ArtNet™ connection
powerCON TRUE1 male connector for power connection

Control

DMX 512 protocol, through DMX cable or wireless system
DMX-RDM compatible
Stand-alone mode and Main/Follow modes
ArtNet™ & sACN protocol through Ethernet cable
Local control panel, with LCD display
Choice of 2 DMX modes (from 14 to 30 DMX channels)

Power Supply

Electronic supply with active PFC
120 to 240 Volts – 50/60Hz
Power: 1,500 W maximum

Cooling System

Advanced cooling system
Self adjusting variable speed fans for quiet operation (Auto mode)
Selectable ventilation user modes with Super Silent mode
Safety protection against temperatures excesses

Housing

Moving-head skeleton made of aluminium and steel metal plates
Base in die-cast aluminium
Heatsinks in aluminium
Moulded covers in self-extinguishing fire retardant ABS PC (V0 class)
Two sides handles for transportation
Four heavy-duty feet for better stability
IP20 protection rating
Exterior finish: black (Carbon)

Installation

Fastening brackets system: two Omega 1/4 turn brackets designed for use with standard clamps
Mounting points: eight 1/4 turn locking fittings allowing installation of Omega brackets on luminaire
Safety cable attachment point

Operating Parameters

Operating positions: all (device on floor or fixed to a support)
Maximum permitted ambient temperature (Ta max): 45 °C (113 °F)
Minimum permitted ambient temperature (Ta min): -10 °C (14 °F)
Minimum usage distance: 3 m (9.84 ft)

Compliance

EU (EMC & LVD)
EMC Directive 2014/30/EU
LVD Directive 2014/35/EU
US (Safety & EMC)
UL 1573
FCC Part 15, Subpart B: 2018
Substance regulations
RoHS
REACH
CP65

Size

Product: 530 x 625 x 280 mm (l x h x d)
Flight-case foam: 580 x 611 x 345 mm (l x h x d)
