Ayrton RawBeam 350 Laser Source IP 65 Moving head Front right of fixtureAyrton RawBeam 350 Laser Source IP 65 Moving head Front right of fixture

Ayrton – RawBeam 350

Ayrton

RawBeam 350 marks the next step in Ayrton’s laser-source development, following over 15 years of work with laser phosphor technology.

SKU: 014350 Categories: , , ,

Description

RawBeam 350 marks the next step in Ayrton’s laser-source development, following over 15 years of work with laser phosphor technology. It has been designed as a practical replacement to the gradual disappearance of traditional dischargelamp sources in beam fixtures. Rather than simply recreating the past, RawBeam 350 uses a modern source designed to deliver the familiar energy and precision expected from this type of light.

Features

Small

Beam 350 is a powerful Phosphor laser-source beam fixture in an extremely compact format. It is as small as Diablo, which has long been considered a reference point for compact moving lights.

Light

At 25.4 kg, RawBeam 350 is lighter and easier to handle than comparable products. This makes rigging, transport and daily use simpler, especially when deployed in large quantities.

Quiet

RawBeam 350 has been designed with highly efficient thermal management. It can cool the engine effectively without needing to run the fans at high speed, making it noticeably quieter in real show conditions.

Narrow

RawBeam 350 reaches an extremely tight 1.1° beam in Beam Mode. This gives sharp, concentrated aerial effects with strong intensity and definition.

Wide

RawBeam 350 opens up to 45° in Spot Mode. This gives more flexibility for wider shots, gobos, prisms and projected effects.

Bright

With its 350 W laser phosphor source, RawBeam 350 delivers very high intensity from a compact fixture. It gives the beam the punch and energy expected from a discharge-style source, with the efficiency and control of laser phosphor technology.

Performance

  • Illuminance at 10 m: > 1,340,000 lx
  • Native CRI: > 68
  • Beam Aperture: 1.1° to 45°
  • Front Lens: 160 mm
  • IP Rating: IP65
  • Weight: 25.4 kg

Video

Ayrton – RawBeam 350 – Presentation

Ayrton RawBeam 350 – Laser Source IP65 3 Series

Additional information

Weight 25.4 kg
Optics

13-element 40:1 zoom high-resolution optic system
Beam aperture: 1.1° to 18° and 2.2° to 45°
Tempered anti-reflective coated lenses
160 mm frontal lens
Light Source

Lux at 10 m: over 1,340,000 lx (narrow angle)
Colour temperature output: 6800 K
Rated life (L70): up to 12,000 hours
Speckle-free source
Movement

Extremely accurate positioning
Moving-head operated via either 8- or 16-bit resolution
Pan and tilt automatic repositioning
Moving-head range: infinite (pan & tilt)
Colours

Sophisticated colour mix system providing CMY colour mixing
Variable CTO colour temperature correction 3000 to 6800 K
Fixed colour wheel with 15 complementary colours, 1 multicolour animation section and 1 gobo correction filter (1/4 CTB)
Gobos

One indexable rotating gobo wheels with 10 Quartz glass gobos (or metal), plus open position
Adjustable-speed rotating gobo in both directions
Fixed multi-position metal gobo wheel with instant access to 25 metal gobos, 4 beam reducers and open position
Gobo diameter (rotating): 16 mm
Image diameter (rotating): 10 mm
Gobo thickness (rotating): 1.1 mm
Frost

Light frost (1°) to soften the edge of the beam
Heavy frost (5°) for Wash effects
Effects

Focusable graphic animation effect-wheel with continuous rotation in both directions (on fixed gobo wheel)
2 set of 3 combinable rotating and indexable prisms
Dimmer / Strobe

Electronic dimmer, allowing perfect light adjustment from 0 to 100% without colour variation
Strobe effect, with speed adjustment from 1 to 25 flashes per second
Software Features

Local DMX addressing of luminaire and optional parameters through its built-in LCD control panel
Remote DMX addressing of luminaire and optional parameters through a standard RDM DMX controller
Information menu including hour counter, temperature, software versio
Hardware Features

Graphic LCD display for addressing and special functions settings, with flip function
5 menu buttons to set functions
Excess temperature protection
Integrated wireless CRMX TiMo RDM receiver from LumenRadio
IP65 XLR 5 pin male and female connectors for DMX connection
IP65 RJ45 IN / OUT connectors for ArtNet and sACN connection
IP65 Power connectors male and female for power connection
Control

DMX 512 protocol, through IP65 DMX cable or a wireless system
DMX-RDM compatible
Stand-alone mode and Main/Follow modes
ArtNet & sACN protocol through Ethernet cable
Local control panel, with IP65 LCD display
Choice of 1 DMX mode (43 DMX channels)
Power Supply

Electronic power supply with active PFC
100 to 240 Volts – 50/60Hz
Power: 660 W maximum
Power: 550 W typical at 230 V
Cooling System

Advanced high-performance cooling system
IP68 Self-adjusting variable speed fans for quiet operation (Auto mode)
Selectable ventilation user modes including Super Silent Mode
Safety protection against excess temperature
Housing

Moving-head skeleton made of aluminium metal plates
Head in die-cast aluminium
Base in die-cast aluminium
Heatsinks in aluminium and copper
Arms covers in self-extinguishing fire retardant ABS PC (V0 class)
Four-side handles for transportation
Four heavy-duty feet for better stability
IP65 protection rating
Exterior finish: black (Carbon)
Installation

Fastening bracket system: two Omega ¼ turn brackets designed for use with standard clamps
Mounting points: four ¼ turn locking fittings allowing installation of Omega brackets on luminaire
Safety cable attachment point
Operating Parameters

Operating positions: all (device on floor or fixed to a support)
Maximum permitted ambient temperature (Ta max): 45°C (113°F)
Minimum permitted ambient temperature (Ta min): -20°C (-4°F)
Minimum usage distance: 25 m (82ft)
Compliance

EU (EMC & LVD)
EMC Directive 2014/30/EU
LVD Directive 2014/35/EU
US (Safety & EMC)
UL 1573
FCC Part 15, Subpart B: 2023
Substance regulations
RoHS
REACH
CP65
Size

Product: 339 x 592 x 297 mm (l x h x d)
Flight-case foam: 395 x 630 x 335 mm (l x h x d)
Product Codes

014350: RawBeam 350 – Laser Source IP65 3 Series
Legal

RAWBEAM is AYRTON registered Trademark
RAWBEAM is a patented model

Downloads

Data Sheet Download
User Guide Download
