Avolites – Tiger Touch II Console

Avolites

With bright screen, increased processing power, and faster graphics engine, the Tiger Touch II is the most specified Titan console.

SKU: 30-01-3020 Categories: , , ,
Clear

Description

Now boasting a 100% brighter screen, increased processing power, and faster graphics engine, the Tiger Touch II is the most specified Titan console.

Feature Quick View

  • Represents the perfect combination of power and portability.
  • Small and light enough to fly in standard hold luggage
  • SMPTE timecode support and a redesigned button layout to match the entire Titan range
  • Generative, animation-based pixel mapping
  • Quicksketch labelling for ultimate personalisation
  • Powerful multi-user networking with any Titan console
  • Create huge effects in seconds with Key Frame Shapes
  • Feature-packed cue lists supporting macros, tracking, autoloads, timecode and more
  • Expand DMX channel capacity with Titan Net Processors
  • Synergy-ready. Add any Ai product to unlock seamless video integration

Additional information

Physical Specification

–
Unit Dimensions (w x d x h)

674 x 435 x 147mm
Weight

15.2Kg
Flight Case Dimensions

750 x 620 x 300mm
Weight in Flight Case

29.4Kg
Power Consumption

80W
Power Specification

110 – 240V AC, 50-60Hz
Heat Output

272.8 BTU/hr
Operating Environment

Ambient temp 0-40C / 32-104F.
Max humidity 95% relative noncondensing
Internal UPS

5 separate 5-minute periods,
fully software integrated
Software

–
Software Platform

Avolites Titan
DMX Channels per Device

8,192
Max DMX Channels per System

32,768
3D Visualisation

Capture engine built in
Max Fixtures

Unlimited
Keyframe Effect Engine

Custom effects with any number
of keyframes
Pixel Mapping

Animation based, video via Synergy
External Control

Web API, MIDI, DMX, sACN
Titan Net

Multi-user with any Titan console
Output Formats

ArtNet, sACN, or DMX512
OS

Microsoft Windows 10 Enterprise
Connectivity

–
DMX 512

4 x Neutrik 5-pin XLR, optically
isolated
Network

2 x 1Gb Ethernet connections
Mains Power

IEC
Data / Peripherals

4 x USB 2.0 plus 1 x USB 2.0
front-mounted
External Display

Display Port and DVI
(one active output only)
MIDI

In & Out 5-pin DIN
SMPTE

3pin XLR
Switch Trigger

¼” jack

Downloads

Data Sheet Download
