Avolites - Sapphire Touch Console Front face of lighting control surface with dual touch screenAvolites - Sapphire Touch Console Front face of lighting control surface with dual touch screen

Avolites – Sapphire Touch Console

Avolites

The performance space you need to manage lighting, video and on-the-night changes

SKU: 30-01-4000 Categories: , , ,

Description

Sapphire is the ultimate Titan package, with the biggest screen real estate and 45 motorised faders.

Feature Quick View

  • 45 Motorised faders
  • 2 responsive, high-brightness touchscreens
  • Integrated UPS
  • Generative, animation-based pixel mapping
  • Quicksketch labelling for ultimate personalisation
  • Powerful multi-user networking with any Titan console
  • Create huge effects in seconds with Key Frame Shapes
  • Feature-packed cue lists supporting macros, tracking, autoloads, timecode and more
  • Expand DMX channel capacity with Titan Net Processors
  • Synergy-ready. Add any Ai product to unlock seamless video integration

Video

LD Profile with Jeff Maker

We sat down with Jeff Maker – Lighting Designer for All Time Low and Dropkick Murphys currently – to chat about his journey into lighting design, his festival experience and love for Avolites!

Additional information

Software

–
Software Platform

Avolites Titan
DMX Channels per Device

8,192
Max DMX Channels per System

32,768
3D Visualisation

Capture engine built in
Max Fixtures

Unlimited
Keyframe Effect Engine

Custom effects with any number of keyframes
Pixel Mapping

Animation based, video via Synergy
External Control

Web API, MIDI, DMX, S-ACN
Titan Net

Multi-user and Backup with any Titan console
Output Formats

ArtNet, S-ACN, or DMX512, any combination
OS

Microsoft Windows 10 Enterprise
Physical Specification

–
Unit Dimensions (w x d x h)

884 x 720 x 218mm
Weight

46kg
Flight Case Dimensions

1000 x 970 x 370mm
Weight in Flight Case

86.5Kg
Power Consumption

100W
Power Specification

110 – 240V AC, 50-60Hz
Heat Output

341 BTU/hr
Operating Environment

Ambient temp 0-40C / 32-104F. Max
humidity 95% relative non-condensing
Internal UPS

5 separate 5-minute periods, fully software integrated
Connectivity

–
DMX 512

8 x Neutrik 5-pin XLR, optically isolated
Network

2 x 1Gb Ethercon individually configured
Mains Power

IEC
Data / Peripherals

4 x USB 3.0, 2 in armrest, 2 on rear pane
External Display

2 x DVI-D
MIDI

In & Out & Thru 5-pin DIN
SMPTE

3pin XLR
Switch Trigger

¼” jack

Downloads

Data Sheet Download
