Avolites-D3-010-FrontAvolites-D3-010-Front

Avolites – D3-010

Avolites

The Avolites D3-010 is the most compact standalone Titan console, supporting 8 universes (4,096 channels) without the need for a laptop. Featuring 10 playback faders, encoder wheels, macro buttons, and USB-C touchscreen support, it delivers full Titan power in a rugged, portable format. With Art-Net, sACN, CITP, SMPTE LTC, and TitanNet multi-console support, it’s perfect for live, touring, and install use.

SKU: 30-02-3010 Categories: , , ,

Description

Access powerful Titan control in our smallest ever portable console. Powered by Titan, the D3-010 supports 8 universes without a laptop: just add a monitor and you’re ready to go. Built for live environments, the D3-010 is compact, tough, travel-ready, and performs straight out of the case.

Features

  • Standalone Titan console with integrated processing, no laptop required
  • Supports 8 DMX universes natively
  • 10 playback faders, 3 encoder wheels, 12 macro buttons and features Avolites’ Compact key layout
  • Compatible with USB-C touchscreen
  • Avolites Titan & Capture Engine
  • 8 Universes (4,096 channels)
  • Unlimited Fixtures
  • TitanNet Multi-Console session
  • Streaming ACN
  • Art-Net & Art-RDM
  • CITP
  • SMPTE LTC

Additional information

Control Surface

External Screens 1x up to 4K (UHD)
Surface Layout: Compact Layout (reduced version of D7 & D9 layout)
Playback Faders: 10x 60mm faders
Flash Buttons: 20x C&K buttons with custom cap
Programming / Setup Keys: 3x Backlit Cherry MX Low Profile keys
Playback Control Keys: 5x back lit Cherry MX Low Profile keys
Macro / Executor Keys: 12x backlight Cherry MX Low Profile Keys
Attribute Control Wheels: 3x high resolution, metal Avo encoders with select buttons
USB Wing Support: 1x D3 Wing, T3 Wing, Or Titan Mobile Wing
D3 Touch Support: Yes (unlimited)
Mobile App: Yes – iOS & Android (“Titan Remote”)
Software

Software Platform: Avolites Titan
Built In 3D Visualisation: Capture Engine
DMX Universes Per Device: 8 universes (4,096)
DMX Universes Per System: 8 Universes (4,096)
MAX Fixtures: Unlimited
Control Protocols:
DMX512 (E1.11)
Streaming CAN (E1.31)
Art-Net & Art-RDM
CITP
GDTF (through Capture)
SMPTE LTC
MIDI over USB (MIDI Notes & MTC)
Web API
Multi-console Session: Yes
TitanNet

Expanded Processing: No
Offload Processing: Yes
Multi-console Session: Yes
Connectivity

External Monitor: 1x USB-C or DisplayPort
Gigabit Ethernet: 2x RJ45
DMX (In & Out: 4x Neutrik 5-pin XLR
USB 3.2 GEN1 (DP Alt Mode): 1x USB-C (rear)
USB 3.2 GEN1: 3x USB-A (1x side, 2x rear)
SMPTE LTC Input (Balanced): 1x Neutrik 3-pin XLR (incl. Signal indicator)
Physical

Weight: 4.6kg
Packaging: Cardboard
Dimensions (W x D x H): 398 x 275 x 78mm
Packaged Dimensions: 575 x 343 X 149mm
Hardware

Operating Voltage: 100-240 , 50/60Hz
Current: 2.4A – 1.1A
Power Connector: Neutrik PowerCON TRUE1
Power Switch: Yes
Soft Power Button: Yes
Power Consumption: 130W max
IP Rating: IP20 (indoor use only)
Operating Temperature: 0-40°C
Humidity: 95% non-condensing
Certification and Safety

Conformity: CE, WEE RoHS

Downloads

Data Sheet Download
