Atera Pixel Brick facing leftAtera Pixel Brick facing left

Astera – PixelBrick

Astera

Multi-purpose light. In addition to being a battery-powered uplight and spotlight with 5 different beam options, multiple PixelBricks can be connected to form clusters and shapes.

SKU: ASTPB15-BBR Categories: , , ,

Description

Multi-purpose light. In addition to being a battery-powered uplight and spotlight with 5 different beam options, multiple PixelBricks can be connected to form clusters and shapes. With about 10cm edge length and 1kg weight, it is small and lightweight while still featuring a powerful output of high-quality light which meets the highest demands of film, TV and stage clients.

Features

Seamless Runtime

To ensure that your light’s batteries last throughout your entire production, you can select how many hours they have to last. This limits the light’s output to a level where you get the maximum brightness to achieve the selected runtime.

Effects

Quickly build programs out of colors and effects, trigger them or make them match a beat. Turn multiple programs and lights into scenes.

Talkback+

Detect all available lights, set them up, check their status, configure DMX addresses and DMX profiles.

Anti-Theft

When enabled, the integrated theft alarm gives visual and audible alarm if lights are being moved. In addition, the AsteraApp also shows the alarm.

Emergency Light

With this innovative feature, the lights can double as a battery-powered emergency light. When activated, the fixture can detect power loss and instantly switches to bright white light to illuminate the venue.

Video

Astera PixelBrick Product Video

Say hello to our multi-purpose light. In addition to being a battery-powered uplight and spotlight with 5 different beam options, multiple PixelBricks can be connected to form clusters and shapes. With about 10cm edge length and 1kg weight, it is small and lightweight while still featuring a powerful output of high-quality light which meets the highest demands of film, TV and stage clients

Additional information

LED Engine

Titan LED Engine

Colors

RGBMintAmber

Total LED Power

15 W

LED Power Draw

12 W

Luminous Flux 2700K

405 lm

Luminous Flux 3200K

475 lm

Luminous Flux 5500K

395 lm

Light Output 2700 K @ 1m

6,178 lx

Light Output 3200 K @ 1m

7,144 lx

Light Output 5500 K @ 1m

5,985 lx

CRI (Ra)/ TLCI 3200- 6500 K*

≥96

Beam Angle

13°

Field Angle

25°

Strobe

0 – 25 Hz

Pixels

1

Battery Runtime

up to 20 hours

Battery Lifetime

70 % after 300 cycles

DC Input

24 VDC – 0.8 A

DC Connector

5.5 mm x 2.1 mm

AC Input

No

AC Connector

No

Power Consumption (max.)

20 W

Wired DMX

Yes via PWB-2-86 (FP1-PWB/ FP3-DTL)

CRMX Receiver

Built-in

BluetoothBridge BTB

Built-in

Wireless Protocols

CRMX, UHF, Bluetooth, WiFi

Wireless Range

CRMX/ UHF up to 300 m / 330 yds Bluetooth up to 3 m / 3.3 yds

Infrared Control

Yes

ControlSync

No

TouchSlider

No

Housing Material

Aluminium

IP Rating

IP65

Ambient Operating Temperature

0 – 40 °C / 32 – 104 °F

Weight

1.12 kg / 2.47 lbs

Dimensions L x W x D

91 mm x 91 mm x 94 mm / 3.6" x 3.6" x 3.7"

Mounting Options

4x Airline Tracks, 4x M5 threads, BrickBracket

Downloads

Data Sheet Download
User Guide Download
